English

Safety Instructions

Observe the following safety guidelines when connecting and using your monitor:

Be sure that your monitor is electrically rated to operate with the AC power available in your location.

Locate your monitor near an easily accessible electrical outlet.

Place the monitor on a solid surface and treat it carefully. The screen can be damaged if dropped, sharply hit, or touched with

a sharp or abrasive implement.

Put your monitor in a location with low humidity and a minimum of dust.

Never use your monitor if the power cable has been damaged. Do not allow anything to rest on the power cable, and keep the

cable away from where people could trip over it.

Never insert anything metallic into the monitor openings. Doing so may create the danger of electric shock.

To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open the monitor's case.

Be sure to hold the plug, not the cable, when disconnecting the monitor from an electrical outlet.

Openings in the monitor cabinet are provided for ventilation. To prevent overheating, these openings should not be blocked

or covered. Also, avoid using the monitor on a bed, sofa, rug, or other soft surface. Doing so may block the ventilation

openings in the bottom of the cabinet. If you put the monitor in a bookcase or other enclosed space, be sure to provide

adequate ventilation.

Do not expose the monitor to rain or use it near water. If the monitor accidentally gets wet, unplug it and contact an

authorized dealer immediately. You can clean the exterior of the monitor with a damp cloth when necessary, but be sure to

unplug the monitor first. If your monitor does not operate normally, in particular, if there are any unusual sounds or smells

coming from it, unplug the monitor immediately and contact an authorized dealer or service center.

NEVER SPRAY OR POUR ANY LIQUID DIRECTLY ONTO THE SCREEN OR CASE.

PLEASE DO NOT USE ANY AMMONIA OR ALCOHOL-BASED CLEANERS ON THE LCD DISPLAY SCREEN OR CASE.

Acer will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.

Attaching the monitor to the base

1.Remove the monitor base from the packaging and place it on a stable and level workspace.

2.Remove the monitor from the packaging.

3.Attach the monitor stand arm to the base.

•Ensure that the base is locked onto the monitor stand arm. (for selected models)

•Secure the base to the monitor stand arm by turning the screw using the integrated tab or a suitable coin. (for selected

models)

Connecting Your Monitor to a Computer

1.Turn off your monitor and unplug your computer’s power cord.

2.2-1Connect Video Cable

a.Make sure both the monitor and computer are powered-OFF.

b.Connect the VGA video cable to the computer.

2-2Connect Digital Cable (Only Dual-input model)

a.Make sure both the monitor and computer are powered-OFF.

b.Connect one end of the 24-pin DVI cable to the back of the monitor and

connect the other end to the computer's port.

2-3Connect HDMI Cable (Only HDMI-input model)

a.Make sure both the monitor and computer are powered-OFF.

b.Connect the HDMI cable to the computer.

Or connect MHL cable to the portable device. (Only for MHL-Input Model)

(Optional)

2-4Connect DP Cable (Only DP-input model)

a.Make sure both the monitor and computer are powered-OFF.

b.Connect the DP cable to the computer.

3.Connect the Audio Cable. (Only Audio-Input Model) (Optional)

4.Connect one end of the adapter to the monitor and the other end to a properly

grounded AC outlet.

5.Power-ON Monitor and Computer.

Power-ON the monitor first, then power-ON the computer. This sequence is very important.

Note: MHL input only works for the MHL-certified device.

External Controls

IconItemDescription

Power button/

indicator

Turns the monitor on/off. Blue indicates power on. Amber indicates standby/power saving

mode.

Minus/PlusIf the OSD is active, press the Minus or Plus button to toggle between the OSD options.

OSD functionsPress to view the OSD. Press again to enter a selection in the OSD.

Auto adjust

button/Exit

If the OSD is active, press Auto to exit the OSD. Once the OSD is inactive, press Auto and the

monitor will automatically optimize the display position, focus, and clock of your display.

Empowering key

Press the Empowering Key to open the Acer eColor Management OSD and access the

scenario modes.

2

D-Sub

DC

HDMI

DC IN

D-SubDVI

HDMI

DC IN

D-SubDVI

AUDIO IN

DC IN

D-SubDVI

DP

AUDIO IN

DC IN

D-Sub

AUDIO IN

HDMI 1 (MHL)HDMI 2 (MHL)

HDMI/DP/HDMI (MHL)

DVI/HDMI (MHL)

/
