ASMB-927 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

•1 x ASMB-927 Startup Manual

•1 x SATA data cable

•1 x SATA power cable

•2 x CPU power cables (8P)

•2 x CPU carriers

•1 x I/O port bracket

•1 x M.2 screw

If any of these items are missing or damaged, please

contact your distributor or sales representative immediately.

Note 1: AcrobatReaderisrequiredtoviewanyPDFle.

Acrobat Reader can be downloaded at:

https://www.adobe.com/downloads.html

(Acrobat is a trademark of Adobe)

ASMB-927 Dual LGA4677 4th Gen Intel

®

Xeon

®

Scalable

EATX Server Board with 16 DDR5, 4 PCIe x16, 9 SATA 3.0,

6 USB 3.2 (Gen1), Dual 10GbE, and IPMI

Startup Manual

Standard M/B Functions

•CPU: Dual LGA4677 4th Gen Intel® Xeon® Scalable

processors

•BIOS:AMI 256 Mbit SPI BIOS

•Chipset: Intel® C741 PCH

•System Memory: 16 x DDR5 3200/3600/4000/4400/4800

MT/s registered ECC DIMM, max. capacity 2 TB

•SATA Interface:

- 8 x SATA 3.0 (6 Gb/s) via Mini SAS HD (SFF-8643),

supports software RAID 0,1,5,10

- 1 x SATA 3.0 (6 Gb/s)

•Serial Ports: One onboard header, only supports RS-232

•Keyboard/Mouse Header: Supports the standard PS/2

keyboard and mouse via PS/2 cable.

•Watchdog Timer: 255 /sec or min level timer intervals

•USB Port: 6 x USB 3.2 Gen1 (4 rear and 2 onboard) and

3 x USB 2.0 (2 onboard and 1 Type-A)

VGA Interface

•Chipset: ASPEED AST2600

•Resolution: Supports VGA up to a resolution of 1920 x

1200 @ 60 Hz refresh rate.

Ethernet Interface

•Interface: 100M/1G/10Gbps

•Controller: LAN1/2: Intel® X710-AT2

Mechanical and Environment

•Dimensions (L x W): 304.8 x 330.2 mm (12” x 13”)

•Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 Vs

•Power Consumption (mainboard only, excluding

I/O devices): Max. load: [email protected], [email protected],

[email protected], [email protected], -12V@0A, [email protected]

•Operating Temperature: 0 ~ 40 °C (depending on CPU)

•Weight: 1.5 kg

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our sup-

port website for ASMB-927 at:

https://advt.ch/asmb927

Register your products on our website and get 2

months extra warranty for free at:

http://www.register.advantech.com

This manual is for the ASMB-927 series Rev. A1

Part No. 2042092700

Printed in China

1st Edition

January 2023
