Seite 1/2
Overview
The EKI-2741 series is designed to convert Gigabit
Ethernet networks to Gigabit fiber networks by
transparently converting Ethernet signals to optic
signals. Therefore, the EKI-2741 series is an ideal
solution for “fiber to building” applications at central
offices or local sites. EKI-2741 series supports
MDI/MDIX auto detection, so you don’t need to use
crossover wires. EKI-2741 series is an enhanced
gigabit Ethernet to fiber optic converter. Furthermore,
the EKI-2741 series can work normally from 0 to
50°C and also is the most cost-effective solution for
fiber optic media converter
Packing List
Before installation, please make sure that you have
received the following:
1 x EKI-2741ML/SL/FL Fiber Optic Gigabit Media
Converters
5V/1A Power Adapter
1 x EKI-2741ML/SL/FL Series Startup manual
If anything is missing or damaged, contact your
distributor or sales representative immediately.
Datasheet
For more detailed information, please refer to the full
specification which can be found on the Advantech’s
website.
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com/products
For technical support and service:
http://www.advantech.com/support/
This startup manual is for EKI-2741ML , EKI-2741SL &
EKI-2741FL.
1st Edition
Sept. 2018
Specifications
General
Compatibility: IEEE 802.3, 802.3u, 802.3ab,
802.3x, IEEE 802.3z
LAN: 10/100/1000Base-T (X), 1000Base-SX or
1000Base-LX
Transmission Distance:
- Ethernet: Up to 100 m
- Fiber:
Multi-mode: Up to 550 m (EKI-2741ML)
Single-mode: Up to 10 km (EKI-2741SL)
- SFP: N/A (EKI-2741FL)
Transmission Speed: Up to 1000Mbps
Optical Fiber:
Multi-Mode (EKI-2741ML)
- Wavelength: 850nm
- Tx Power: -4 / -9.5 dBm
- Rx Sensitivity: -17 dBm
- Parameters: 50/125 um, 62.5/125 um
Single-Mode (EKI-2741SL)
- Wavelength: 1310nm
- Tx Power: -3/-9.5 dBm
- Rx Sensitivity: -20 dBm
- Parameters: 9/125 um
Connectors:
1 x RJ45
1 x SC type fiber connector (EKI-2741ML/SL) or
1 x SFP type fiber connector (EKI-2741FL)
LED Indicators:
EKI-2741ML/SL FIBER, LAN, PWR
EKI-2741FL Fiber: LINK/ACT
LAN: LINK/ACT
PWR
Operating Current: 0.61A (EKI-2741ML/SL)
0.52A (EKI-2741FL)
Power Adapter: 5V DC, 1A external power
adapter
Power Consumption: 0.5 W (EKI-2701FL, w/o
insert SFP transceiver)
Dimensions (W x H x D):
EKI-2741FL: 60.88 x 23 x 75.58 mm
(2.4" x 0.91" x 2.98")
EKI-2741ML/SL: 75 x 22.6 x 101.2 mm
(2.95" x 0.89" x 3.98")
Enclosure: IP30
Operating Temperature: 0 ~ 50°C (32 ~ 122°F)
Storage Temperature: -40 ~ 70°C (-40 ~ 158°F)
Humidity: 10 ~ 95% (non-condensing)
Safety: LVD
EMC: CE, FCC
Warranty: 2 years
