MIC-75M20-00 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

1. MIC-75M20-00 i-Module

P/N: MIC-75M20-00C1

2. MIC-75M20-00 Startup Manual P/N: 20015M2022

3. Card clamp pads x 2 P/N: 1990024989T010

4. Wallmount bracket (Left) P/N:

1960070545T001

5. Wallmount bracket (Right) P/N:

1960070543T00A

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

le. Acrobat Reader can be downloaded at: get.

adobe.com/reader (Acrobat is a trademark of

Adobe.)

MIC-75M20-00

PCIe Expansion Module for MIC-7 Series Embedded

Systems

Startup Manual

PCIe Slots

•1 x PCIe x16 socket

Note 1: PCIe x16 supports up to 75W power consump-

tion.

•1 x PCIe p1-x4 socket

Note 1: PCIe p1-x4 supports up to 25W power consumption.

Note 2: MIC-75M20 does not support MIC-7300 series

systems.

•1 x 12V extra power socket

Note 1: 12V extra power connector supports 25~75W.

Note 2:The total power consumption of the M20 riser

card can support 100W (PCIe x16 socket + PCIe

x4 socket + 12V extra power)

Environment

•Operating Temperature:

-20 ~ 60°C with 0.7 m/sec air ow with 1 x Industrial SSD,

without PC expansion boards

0 ~ 45°C with 0.7 m/sec air ow with 1 x 2.5” HDD,

without PC expansion boards

•Storage Temperature: - 40 ~ 85°C (-40 ~185°F)

•Relative Humidity: 95% @ 40°C (non-condensing)

Mechanical

•i-Module dimensions (H x W x D): 50 x 192 x 230 mm

•With MIC-7 series (H x W x D): 127 x 192 x 230 mm

Note: We suggest adding an optional system fan (P/N:

98R1752000E) if power consumption of your

add-on card is more than 45W (for better thermal

management).

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

https://www.advantech.com/en/support

This manual is for the MIC-75M20-00 Rev. A1.

Part No. 20015M2022

Printed in China

2nd Edition

December 2024
