MIO-4370 Startup Manual 1

Before you begin installing your system, please make sure

that the following items have been shipped:

1. 1 x MIO-4370 SBC

2. 1 x USB 2.0 Cable 20cm (P/N: 1700030406-01)

3. 1 x Audio Cable 20cm (P/N: 1700019584-01)

4. 2 x COM Cable 20cm (P/N: 1700030404-01)

5. 1 x Startup Manual (P/N: 2046437000)

6. 1 x Screw Kit (3 x M3x5L screws for the M.2 module, 4

sets of screws and stand-o󰀨)

7. 1 x Jumper Kit (10 x Jumpers)

8. 1 x WISE-DeviceOn Package

9. 1 x McAfee/Acronis Package

If any of the above items are missing or damaged, contact

your distributor or sales representative immediately.

Note 1: For detailed contents regarding MIO-4370,

please refer to information on the support web-

site: https://www.advantech.com/en/support.

Note 2: Adobe Reader is required to view any PDF le.

Adobe Reader can be downloaded at: https://get.

adobe.com/reader/otherversions/ (Adobe is the

trademark of Adobe Systems Incorporated.)

MIO-4370

12th/13th Gen. Intel

®

Core™Processor (LGA1700

Socket Type), 4" EPIC SBC, DDR5, Dual HDMI,

eDP, 2 x 2.5GbE with TSN, 4 x USB 3.2, CAN Bus,

TPM

General

•CPU:

- Intel

®

Core™ i9-12900TE (16 Cores / 24 Threads, up to

4.8 GHz)

- Intel

®

Core™ i7-12700TE (12 Cores / 20 Threads, up to

4.6 GHz)

- Intel

®

Core™ i5-12500TE (6 Cores / 12 Threads, up to

4.3 GHz)

- Intel

®

Core™ i3-12100TE (4 Cores / 8 Threads, up to

4.0 GHz)

•Chipset: R680E/H610E

•System memory: DDR5-4800 up to 32GB, SODIMM,

Single Channel

•BIOS: AMI UEFI 256Mbit

•Watchdog timer: 65536 level, 0~65535 sec (Multi-level

WDT)

•TPM: Support

•Battery: Lithium 3V/220mAH

•Audio: Supports High Denition Audio (HD), Line-in, Line-

out, and Mic-in.

Expansion Interface

• 2 x M.2 M-Key (Chipset: R680E ) or 1 x M.2 M-Key (Chip-

set: H610E) for 2280 module (PCIe Gen 4 x4)

• 1 x M.2 E-Key for 2230 module (PCIe x1, USB 2.0)

• 1 x M.2 B-Key (Chipset: H610E only) with SIM slot for

3042 module (USB 2.0 only)

Display

•Controller:

- Intel

®

UHD Graphics 770 with 32 Execution Units

- Intel

®

UHD Graphics 730 with 24 EUs (i3-12100TE only)

•Maximum resolution:

- LCD: 1 x eDP 1.4b, up to 5120 x 3200 @ 60Hz, 24bpp

- HDMI: 2 x HDMI 1.2, up to 1920 x 1200 @ 60Hz, 24bpp

•Multiple displays: eDP + HDMI + HDMI

Ethernet Interface

•Controller: LAN1/LAN2: Intel® i225

•Speed: LAN1/LAN2: up to 2.5GbE with TSN support

I/O

•External I/O: 2 x RJ-45, 2 x HDMI, 4 x USB 3.2

•Internal I/O: 2 x USB 2.0, 2 x RS-232/422/485, CANBus,

I

2

C, Audio, GPIO, Front Panel

•Power connector type:ATX 2x2 pin 180D (Optional ATX

2x2 pin 90D)

Specications Packing List

For more information about this and other Advantech

products, visit our website at:

https://www.advantech.com/en

For technical support and customer service, visit our

support website at:

https://www.advantech.com/en/support

This manual is for the the MIO-4370 series.

Part No. 2046437000

Printed in China

Edition 1

March 2023
