PCE-3032/PCE-4132 Startup Manual 1

Before you begin installing your card, please ensure the

following items have been shipped:

1. 1 x PCE-3032/PCE-4132 PICMG 1.3 System Host

Board

2. 1 x PCE-3032/PCE-4132 Startup Manual

3. 1 x Serial ATA HDD data cable

4. 1 x 2-port COM cable kit

5. 1 x 4-port USB 2.0 cable kit

6. 1 x Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

PCE-3032/PCE-4132 LGA1200 Intel

®

Xeon

®

, Core™

i9/i7/i5/i3/Celeron

®

/Pentium

®

PICMG 1.3 Half-size

System Host Board with DDR4/Dual GbE LAN

Startup Manual

General

•CPU:LGA1200-socket Core™ i9/i7/i5/i3, Pentium

®

and

Xeon

®

W series processors

Note:Only PCE-4132 supports Intel

®

Xeon

®

processors.

•L2Cache: Please refer to CPU specication for detailed

information.

•BIOS:AMI SPI BIOS 256Mb (PCE-4132)/128Mb (PCE-

3032)

•SystemChipset:Intel

®

W480E (PCE-4132)/Intel®

H420E (PCE-3032)

•Systemmemory:

- PCE-4132: Up to 64 GB in 2 x 260-pin SODIMM sock-

ets. Supports dual-channel DDR4 2666/2933 SDRAM

with or without ECC function.

- PCE-3032: Up to 64 GB in 2 x 260-pin SODIMM sock-

ets. Supports dual-channel DDR4 2666/2933 SDRAM

without ECC function.

•SATAharddiskdriveinterface:PCE-3032 supports 3

x SATA 3.0 ports without RAID function, and PCE-4132

supports 4 x SATA 3.0 ports with SW RAID 0,1,5,10.

•Serialports:2 x RS-232 serial ports

•Watchdogtimer:Programmable 1~255 sec

•USB:4 x USB 3.0 and 6 x USB 2.0

•GPIO:1 x programmable 8-bit GPIO pin-header

Display

•Chipset:Intel

®

HD Graphics embedded in the processor.

EthernetInterface

• Chipset supports:

-

LAN 1: Intel

®

I210AT (PCE-3032) and I210AT (PCE-

4132).

-

LAN 2: Intel

®

I210AT (PCE-3032) and I210AT (PCE-

4132).

• Connection: 2 on-board RJ-45 connectors with LED

indicators.

MechanicalandEnvironmental

• Dimensions: (L x W): 172.6 x 126.3 mm/6.7 x 4.97 in

• Power supply voltage: +3.3 V, +5 V, +12 V, 5 VSB

• Power requirements:

CPU:Intel®i7-10700ECPU@2.90GHz,DDR:4GBSO-

DDR4-2666*2

Voltage+V12+V5_SB+V3.3+V5

Current 4.36A0.17A1.8A2.13A

• Operating temperature: 0 ~ 60 °C / 32 ~ 140 °F (depend-

ing on CPU)

• Weight: 0.33 kg / 72 lb (weight of board)

SpecicationsPackingList

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

https://www.advantech.com/support

This manual is for the PCE-3032/PCE-4132 Series Rev. A2.

PCE-3032: PCE-4132:

Part No. 2041303201

Printed in China

2nd Edition

October 2022
