1 Startup Manual
Packing List
Before installation, please make sure that you have received
the following:
•PCI-1737U card
•Driver CD
•Quick Start User Manual
If anything is missing or damaged, contact your distributor or
sales representative immediately.
User Manual
For more detailed information on this product, please refer to
the 1737U User Manual on the CD-ROM (PDF format).
Specifications
Digital Input
Number of Input Channels
24 (Shared with output)
Compatibility
5V/TTL
Interrupt Inputs
1 (PC00)
Input Voltage
Logic 0 : 0.8 V (max.)
Logic 1 : 2 V (min.)
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause interference in which case the user is
required to correct interference at his own expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This kind
of cable is available from Advantech. Please contact your
local supplier for ordering information.
Notes
For more information on this and other Advantech products,
please visit our websites at:
http://www.advantech.com
For technical support and service:
http://www.advantech.com/support/
This startup manual is for PCI-1737U.
Part No: 20031737201st Edition
July 2015
STARTUP MANUAL
Overview
PCI-1737U
24 channel Digital I/O Universal PCI Card
The PCI-1737U is a 24-bit DI/O card with PCI bus . It pro-
vides you with 24 bits of parallel digital input /output. It emu-
lates mode 0 of the 8255 PPI chip , but the buffered circuits
offer a higher driving capability than the 8255.The I/O bits
are divided into three 8-bit I/O ports: A0, B0, and C0.You can
configure each port as either input or output via software.
General
I/O Connector Type
50-pin box header
Dimensions
170 mm x 100 mm (6.9” x 3.9”)
Power Consumption
+5V @ 300 mA (max.)
Temperature
Operation0 ~ +60°C (32~ 140°F )
(refer to IEC 68 -2 - 1 ,2)
Storage-20 ~ +70°C (-4 ~158°F)
Relative Humidity
5 ~ 95% RH non-condensing
(refer to IEC 60068-2-3)
Certification
CE/FCC
Digital Output
Number of Output Channels
24 (Shared with input)
Compatibility
5V/TTL
Input Voltage
Logic 0 : 0.8 V max. @+24
mA (sink)
Logic 1 : 2 V min. @-15 mA
(source)
