PCM-3117 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

•1 PCM-3117 module

•1 Start-up manual

•1 Signal cable 4P to 4P P/N: 1700001898

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

The PCM-3117 is PCI to ISA bridge module.

For other PCI-104 bus applications, PC104+ module should

be used. For all modules to be compatible, PCM-3117 is

the solution.

For OS limitations, users must install PCM-3117 first, then

install the OS, or the computer can not recognize PCM-

3117.

Introduction

PCM-3117 PCI to ISA Bridge Module

Startup Manual

•PCM-3117 PCI to ISA Bridge Module

•Compatible with PC/104 and PC/104+

•PCI-104 CPU module (PCM-3380) to control PC/104

peripheral (ISA bus)

•Supports Windows NT 4.0, Windows 98/2000/XP/SE

•Controller: ITE IT8888F

•Bus:PC/104(ISA) and PC/104+(PCI)

•Plug&Play:Supports Plug & Play automatic detection &

configuration

•PC/104expansion: 104-pin and 120-pin 16/32-bit PC104

/Plus module connector

•OperatingVoltage: +5 V only

•PowerConsumption:+5 @ 70 mA (Typical)

•Size/Weight:96 x 90 mm (3.8” x 3.5”), 90 g (0.198 lb)

•Environment:0 ~ 60C (operation), -40 ~ 85 ° ° C

(storage)

•Humidity:0 ~ 90%

Specications

Features

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://support.advantech.com/

This manual is for the

PCM-3117

series Rev. A1.

Part No. 2006311702

Printed in China

3rd Edition

September 2015
