LED Outdoor Luminaires

Wall Mount

120VAC / 60Hz

Page 1 of 1 R18061226

Part #: TPWW70050LWH

Limited Factory Warranty

AFX Inc. hereby warranty that this xture is free from defects in materials and workmanship when installed and used under normal operating conditions

for a period of 5 years from date of shipment from factory. This warranty covers all component parts and extends only to replacement of defective xture

or components; it does not cover failure due to improper installation, misuse, mishandling or damage incurred in transit.

Safety Precautions

Read all safety precautions and installation instructions carefully before installing or servicing this xture. Failure to comply with these instructions could result in potentially fatal

electric shock and/or property damage.

It is recommended that a qualied electrician perform all wiring. This xture must be wired in accordance with all national and local electrical codes.

Do not handle any energized xture or attempt to energize any xture with wet hands or while standing on a wet or damp surface or in water.

This xture is designed for use in a 120VAC, 60Hz fused circuit. This xture is not compatible with dimmers.

Make sure that the power source conforms to the requirements of the xture. (See labels on the xture housing).

To reduce the risk of electrical shock, and to assure proper operation, this xture must be adequately grounded. To accomplish proper grounding, there must be a separate ground

wire (green) contact between this xture and the ground connection of your main power supply panel.

This xture is intended to be used for general outdoor lighting in dry, damp or wet locations. For wet locations, xture must be mounted 48” above ground level.

Disclaimer

Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been

tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Canadian IC/ NMBES-005 (B) -005 (B). These limits are designed to

provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiver antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult with the dealer or an experienced radio/TV technician for help.

Any modications to this xture may void the warranty and interfere with the safe operation of the luminaire.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may

cause undesired operation of the device.

Assembly Instructions

Step 1 Preparing for installation–

A. at fuse or circuit breaker box before installing or Disconnect electrical power

servicing any part of this xture.

B. Remove xture from carton; remove components from hardware kit.

C. Place the diuser assembly (7) and hardware o to the side.

D. Installbracket (1) to junction box (not supplied) with two screws (2) to secure it.

E. Install stem (3) to bracket (1) using washer and jam nut (4) to secure it.

Wiring All wiring must take place inside junction box (not included) –

Caution: Make sure power is o at fuse or circuit breaker box. Check power wires for

damage or scrapes. If power supply wires are within three inches of the LED driver,

use wire suitable for at least 90°C (194°F). st dwellings built before 1985 Note:Mo

have supply wire rated to 60°C. Consult a qualied electrician to ensure correct branch

circuit conductor before installing.

Step 2 Wiring xture –

A. Make all wire connections to appropriate wire. Secure with wire nuts (provided).

B. Connect the green wire from the xture to the ground wire from supply power source.

C. Connect the black wire from the xture to the black (L) wire from supply power source.

D. Connect the white wire from the xture to the white (N) wire from supply power source.

E. Pull on each wire lead to make sure connections are secure. Make Do not mix wires.

certain no bare wires are exposed outside of wire connectors. Tuck all connections

neatly into junction box.

Step 3 Back pan mounting –

A. Install xture housing (5) by aligning center hole to stem (3) then using barrel nut (6) to

secure it.

Step 4 Mounting diuser –

A. Install the diuser (7) by aligning two holes on top and bottom to housing (5) then using

two screws (8) to secure it.

Step 5 For wet application –

A. Apply a small amount of clear silicone (not included) per manufacturer’s instruction around screws

(8) and around the diuser frame (7) and housing (5)where it contacts with the surface of the wall

on three sides only. Do not caulk on the bottom.

Step 6 Restore power at fuse or circuit breaker box –
