LE-22, LE-24 & LE-27 LED-Backlit Display

User Manual

TABLE OF CONTENTS

SAFETY PRECAUTIONS. ................................................................................. 3

FOR YOUR SAFETY .................................................................................... 3

SPECIAL NOTES ON LCD MONITOR ...................................................... 5

BEFORE YOU OPERATE THE MONITOR .................................................... 6

FEATURES .................................................................................................... 6

CHECKING THE CONTENTS OF THE PACKAGE. ................................ 6

INSTALLATION INSTRUCTIONS ............................................................... 6

ADJUSTING THE VIEWING ANGLE. ........................................................ 7

CONNECTING CABLES .............................................................................. 8

GENERAL INSTRUCTIONS ...................................................................... 10

EXTERNAL CONTROLS ............................................................................ 10

OPERATING INSTRUCTIONS. ...................................................................... 11

FRONT PANEL CONTROL. ...................................................................... 11

HOW TO ADJUST A SETTING ................................................................. 12

ADJUSTING THE PICTURE...................................................................... 13

PLUG AND PLAY ........................................................................................ 15

TECHNICAL SUPPORT (FAQ) ....................................................................... 16

ERROR MESSAGE & POSSIBLE SOLUTION ....................................... 17

APPENDIX ......................................................................................................... 20

SPECIFICATIONS ....................................................................................... 20

FACTORY PRESET TIMING TABLE ....................................................... 22

CONNECTOR PIN ASSIGNMENT ........................................................... 24

PRODUCT DIMENSIONS .......................................................................... 27

FOR YOUR SAFETY

Before operating the monitor, please read this manual thoroughly. This manual

should be retained for future reference.

SAFETY PRECAUTIONS

FCC Class B Radio Frequency Interference Statement

WARNING: (FOR FCC CERTIFIED MODELS)

This device complies with Part 15 of the FCC rules.Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received,including interference that may

cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy, and if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

NOTICE:

1. The changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

2. Shielded interface cables and AC power cord, if any, must be used in order to

comply with the emission limits.

3. The manufacturer is not responsible for any radio or TV interference caused by

unauthorized modification to this equipment. It is the responsibilities of the user

to correct such interference.

WARNING:

To prevent fire or shock hazard, do not expose the monitor to rain or moisture.

Dangerously high voltages are present inside the monitor. Do not open the cabinet.

Refer servicing to qualified personnel only.

Produktspezifikationen

Marke:	AG Neovo
Kategorie:	Monitor
Modell:	LE-22
Touchscreen:	Nein
Bildschirmdiagonale:	21.5 "
Bildschirmtechnologie:	LED
Anzahl der Farben des Displays:	16,78 Millionen Farben
Eingebaute Lautsprecher:	Ja
WLAN:	Nein
Bluetooth:	Nein
Mitgelieferte Kabel:	AC, Audio (3.5mm), VGA
Produktfarbe:	Schwarz
Höhenverstellung:	Ja
Neigungsverstellung:	Ja
RMS-Leistung:	4 W
AC Eingangsspannung:	100 - 240 V
AC Eingangsfrequenz:	50 - 60 Hz
Betriebstemperatur:	0 - 40 °C
Relative Luftfeuchtigkeit in Betrieb:	10 - 85 %
Verpackungsbreite:	677 mm
Verpackungstiefe:	173 mm
Verpackungshöhe:	403 mm
Paketgewicht:	6400 g
Zertifizierung:	CB, CE, RoHs, FCC, BSMI, WEEE
Display:	LED
Stromverbrauch (Standardbetrieb):	33 W
Plug & Play:	Ja
HD-Typ:	Full HD
Natives Seitenverhältnis:	16:9
Reaktionszeit:	7 ms
Bildwinkel, horizontal:	178 °
Bildwinkel, vertikal:	178 °
Anzahl HDMI-Anschlüsse:	1
Anzahl der Lautsprecher:	2
Stromverbrauch (Standby):	0.5 W
Energieeffizienzklasse (alt):	A
LED-Anzeigen:	Leistung
Jährlicher Energieverbrauch:	27 kWh
Kontrastverhältnis (dynamisch):	20000000:1
PC Audio-Eingang:	Ja
Gewicht (ohne Ständer):	2700 g
Breite (ohne Standfuß):	509.6 mm
Tiefe (ohne Standfuß):	49 mm
Höhe (ohne Standfuß):	310 mm
VESA-Halterung:	Ja
Unterstützte Video-Modi:	1080p
Unterstützte Grafik-Auflösungen:	1920 x 1080 (HD 1080)
DVI Anschluss:	Ja
Panel-Montage-Schnittstelle:	100 x 100 mm
Gerätebreite (inkl. Fuß):	509.6 mm
Gerätetiefe (inkl. Fuß):	244.5 mm
Gerätehöhe (inkl. Fuß):	530.6 mm
Gewicht (mit Ständer):	4900 g
Ein-/Ausschalter:	Ja
Neigungswinkelbereich:	-5 - 22 °
Kabelsperre-Slot:	Nein
Anzahl VGA (D-Sub) Anschlüsse:	1
Seitenverhältnis:	16:9
Stromverbrauch (aus):	0.5 W
Höheneinstellung:	130 mm
Panel-Typ:	IPS
Helligkeit (typisch):	250 cd/m²
Pixel Abstand:	0.248 x 0.248 mm
Digital horizontale Frequenz:	30 - 83 kHz
Digital vertikale Frequenz:	56 - 76 Hz
TV Tuner integriert:	Nein
Display-Oberfläche:	Matt
Pivot:	Ja
Pivot Winkel:	0 - 90 °
Schwenkbar:	Ja
Schwenkwinkelbereich:	-160 - 160 °
Thin Client installiert:	Nein
Benutzerhandbuch auf CD-ROM:	Ja
Display-Auflösung:	1920 x 1080 Pixel
Ethernet/LAN:	Nein
