Filter Twin®
The Filter Twin uses two identical filters sweeping in opposite directions, one up
and one down. This unique design creates classic 70’s-inspired funk sounds and
completely new and original filter tones.
The Filter Twin employs an intuitive four-knob layout. The blend control pans
between the filters, allowing the user to mix how much of each filter they hear.
The threshold control determines how sensitive the unit is to different playing
styles, while the velocity controls determine the speed of each filter.
Features:
• Separate velocity controls for the each filter
• Blend control allows for panning between filters
• Gig-saver bypass (signal passes even if your battery dies)
• Power: Nine-volt battery or optional universal power supply
• Heavy duty steel construction
• Battery life >75 hours
Owner’s Manual
Manual Version 1.0
I. Functions
A. Top Panel Controls:
BLEND: Pans between the up and down filters. The “up” filter control is
indicated by an arrow pointed up. The “down” filter control is indicated by a
down arrow.
THRESHOLD: Controls the sensitivity of the unit to different input levels
VELOCITY UP: Controls the speed of the up filter*
VELOCITY DOWN: Controls the speed of the down filter*
ENGAGE: Toggles between engage and bypass. The blue LED indicates that the
effect is engaged.
*The filter velocity also depends on threshold settings and input level. As the
threshold is lowered and your bass’ input level is increased, the filter velocity
increases as well – so tweak away and have fun!
B. Side Panel Connections:
IN: ¼” input
DC IN: This is a standard 2.1mm DC jack. The center terminal polarity is
negative.
OUT: ¼” output
C. Specifications:
Current consumption:………………………..10mA
Input impedance: ............................................1MΩ (Effect On)
Output impedance: .........................................1 K Ω
Maximum Output:…….……………………..+6dBu (1.6VRMS)
Battery Life…………………….……………..~75 hours
Noise Level: .................................................…-94 dBu ‘A’ weighted *
External DC Power:………………………..9-10VDC, 20mA min, center
terminal negative
* = All knobs set to 12 oʹclock
II. Sample Settings
Please visit our website, www.aguilaramp.com, for sample settings.
III. “How To”s
How to change the battery:
This operation can be done quickly and easily and requires no tools!
The battery is easily accessible by loosening the thumbscrew on the bottom of the
unit.
The battery compartment will slide forward and you will be able to see the
padded area to insert the battery and attach the battery clips. Once the battery
has been replaced, simply slide the compartment back in and hand tighten the
thumbscrew.
How to attach the unit to a pedal board:
We have included two neoprene spacers to help attach the unit to a pedal board.
These pieces can be attached as shown to the bottom of the unit.
Once the neoprene spacers are secured to the bottom of the pedal, you can then
affix a piece of Velcro to them – you are now ready to mount the Filter Twin to
your pedal board!
We have included an additional screw that can be used to replace the
thumbscrew if itʹs in the way of your board.
