Seite 1/5
User Instructions
American DJ®
4295 Charter Street
Los Angeles, CA. 90058
www.americandj.com
4/03
Flash Duo™ Introduction
Introduction: Thank you for purchasing the Flash Duo™ by
American DJ®. The Flash Duo™ is ready to be plugged in right
out of the box and does not require any type of controller to
operate. The Flash Duo™ comes with two spinning heads that
operate on an independently rotating base. The speed in which
this unit rotates is adjustable. This unit produces multiple strob-
bing clear beams of light that creates unique patterns on the
floor and walls. To optimize beam intensity use this fixture with a
fog machine or other type of special effect smoke.
Customer Support: American DJ® provides a toll free customer
support line, to provide set up help and to answer any question
should you encounter problems during your set up or initial oper-
ation. You may also visit us on the web at www.americandj.com
for any comments or suggestions. For service related issue
please contact American DJ®. Service Hours are Monday
through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
Warning! To prevent or reduce the risk of electrical shock or fire,
do not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do
not attempt any repairs yourself, doing so will void your manu-
factures warranty. In the unlikely event your unit may require ser-
vice please contact your nearest American DJ® dealer.
PLEASE do not discard the shipping carton in the trash.
Please recycle when ever possible.
© ®American DJ - www.americandj.com - Flash Duo™ Instruction Manual Page 2
© ®American DJ - www.americandj.com - Flash Duo™ Instruction Manual Page 3
Flash Duo™ Warranty Registration
• Adjustable Speed Knob (4 settings)
• Reverse Switch
• Easy Lamp Replacement.
• Air Cooled.
• Light Weight, Compact Case Design.
• Built-In Mounting Plate.
• 2 x ZB-50
• Low Power Consumption.
Flash Duo™ Features
Every Flash Duo™ has been thoroughly tested and has been
shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your unit
for damage and be sure all accessories necessary to operate the
unit have arrived intact. In the event damage has been found or
parts are missing, please contact our toll free customer support
number for further instructions. Please do not return this unit to
your dealer without first contacting customer support.
Flash Duo™ Unpacking
The Flash Duo™ carries a 90 day limited warranty. We recom-
mend you fill out the enclosed warranty card to validate your
purchase. All returned service items whether under warranty or
not, must be freight pre-paid and accompany a return autho-
rization (R.A.) number. If the unit is under warranty, you must
provide a copy of your proof of purchase invoice. Please con-
tact American DJ® customer support for a R.A. number.
© ®American DJ - www.americandj.com - Flash Duo™ Instruction Manual Page 4
Flash Duo™ Precautions
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been frayed
or broken. Please route your power cord away from foot trafc.
• Do not attempt to remove or break off the ground prong from the
electrical cord. This prong is used to reduce the risk of electrical
shock and re in the event of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the bottom cover under any conditions. There are
no user serviceable parts inside.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit if it becomes damaged in any way.
• Never operate this unit when it’s front cover is removed.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-Cord Protection - Power-supply cords should be route so
they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords a plugs,
convenience receptacles, and the point where they exit from the
fixture.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer.
• Heat -The fixture should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The fixture does not appear to operate normally or exhibits a
marked change in performance.
© ®American DJ - www.americandj.com - Flash Duo™ Instruction Manual Page 5
Flash Duo™ Operation
Power Supply: Before plugging your unit in, be sure the source
voltage in your area matches the required voltage for your
American DJ® Roto-Balls.™ The American DJ® Roto-Balls
™
is available in a 120v and 220v version. Because line voltage
may vary from venue to venue, be sure to plug your xture into
a wall outlet with a matching power supply before attempting to
operate.
General Operation: Just plug this light in, and watch it go. This
fixture is designed to operate as a stand alone unit. The Flash
Duo™ is ready to be plugged in, out of the box. There is no
power switch, after plugging the unit in the base and two outer
heads will immediately begin to spin. The flash rate can be
adjusted by turning the flash rate adjustments knob located on
the top of the unit.
Adjustable Speed Knob: The speed at which this unit spins
can be adjusted by turning the knob located at the base of
the unit. The knob has four speed settings. When the knob is
turned all the way counter-clockwise it will spin the slowest at
7 r.p.m. By turning the knob clockwise to the second position
which spins at 16 r.p.m. The next position will spin at 26 r.p.m.
Until, it is turned all the way clockwise and it spins the fastest
at 35 r.p.m.
Reverse Switch: The direction this unit rotates can also be
switched. To reverse the rotation of the unit, press the reverse
switch. The reverse switch is located on the base of unit next to
the AC cord.
Please carefully read and understand the instructions in this
manual thoroughly before attempting to operate this unit. These
instructions contain important safety information regarding the
use and maintenance of this unit. Please keep this manual with
the unit, for future reference.
Flash Duo™ General Instructions
© ®American DJ - www.americandj.com - Flash Duo™ Instruction Manual Page 6
Flash Duo™ Lamp Replacement
Caution: Always replace with the exact same type lamp, unless
otherwise specified by an authorized American DJ® technician.
Replace with anything other than the specified part can dam-
age your unit and will void your manufactures warranty.
Warning: If after you have replaced the lamp and you continue
to blow them, STOP using the unit. Contact customer support
for further instructions, you may have to return the unit for ser-
vicing. Continuing to use the unit may cause serious damage.
Lamp Replacement: Caution! Never open the unit when in
use. Always disconnect the main power and allow the fixture
ample time to cool before attempting to replace the lamp. Lamp
replacement has been made simple by incorporating a remove
tray that is retained by a single thumb screws. Again, please
remember to always replace with the exact same type lamp.
1. Be sure to follow the proper procedures when handling
halogen lamps. Never touch the new lamp with your bare fin
gers.
2. Unscrew the three thumb screws that secure the outer half of
the dome cover to the inner half.
3. Once the thumb screws have been removed, remove the
outer
half of the dome assembly to expose the lamps.
4. Remove and replace the lamp with an exact match.
5. Reassemble in reverse order.
Halogen Lamp Warning! This fixture is fitted with
halogen lamps which are highly susceptible to dam-
age if improperly handled. Never touch the lamps
with your bare fingers as the oil from your hands will
shorten lamp life. Also, never move the fixture until
the lamps have had ample time to cool. Remember,
lamps are not covered under warranty conditions.
