User Instructions
Fusion FX Bar 5 Introduction
© ®American DJ Supply - www.americandj.com - Fusion FX Bar 5 Instruction Manual Page 2
Rev. 3/14
Unpacking: Thank you for purchasing the Fusion FX Bar 5 by Ameri-
can DJ . Every Fusion FX Bar 5 has been thoroughly tested and has ®
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without rst contact-
ing customer support.
Introduction: The Fusion FX Bar 5 is part of American DJ’s continu-
ing pursuit for creating high quality affordable intelligent fixtures. The
Fusion FX Bar 5 is a DMX intelligent LED wash & laser fixture. The unit
has 3 operating modes; Sound Active (with adjustable sound sensitiv-
ity), Show Mode, or DMX Control. This unit can be used as a stand
alone xture, or in a Master/Slave conguration.
Customer Support: American DJ provides a toll free customer sup®-
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ .®
PLEASE recycle the shipping carton when ever possible.
Fusion FX Bar 5 Safety Precautions
© ®American DJ Supply - www.americandj.com - Fusion FX Bar 5 Instruction Manual Page 4© ®American DJ Supply - www.americandj.com - Fusion FX Bar 5 Instruction Manual Page 3
• White LED Wash/Strobe Effect, 1 TRI Color LED Moonflower, & 1
Green Laser
• Strobing
• Built in Microphone
• DMX-512 protocol - Seven DMX Modes
• 16 Show Modes, 1 Radom Show Mode
• 3 Operating Modes - Sound Active, Show Mode, or DMX Control
• Sound Sensitivity Adjustable
• UC3 Remote Control Compatiable (Not Included)
• Power Cord Daisy Chaining. See page 16.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 19 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu-
d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
Fusion FX Bar 5 Warranty Registration
Fusion FX Bar 5 Features
To optimize the performance of this product, please read these operat-
ing instructions carefully to familiarize yourself with the basic operations
of this unit. These instructions contain important safety information
regarding the use and maintenance of this unit. Please keep this manual
with the unit, for future reference.
CAUTION IMPORTANT! When installing this projector, make sure
that it is mounted in a manner that prevents the audience from
looking directly into the beam, and the beam from striking the
audience.
Fusion FX Bar 5 General Instructions
The Fusion FX Bar 5 carries a 2 year (730 days) limited warranty for
LEDs and a 90 Day limited warranty for the laser. Please fill out the
enclosed warranty card to validate your purchase and warranty. You
may also register your product online at www. americandj.com. All
returned service items whether under warranty or not, must be freight
pre-paid and accompany a return authorization (R.A.) number. If the
unit is under warranty you must provide a copy of your proof of pur-
chase invoice. Please contact American DJ® customer support for a
R.A. number.
©American DJ® - www.americandj.com - Fusion FX Bar 5 Instruction Manual Page 5
© ®American DJ Supply - www.americandj.com - Fusion FX Bar 5 Instruction Manual Page 6
Fusion FX Bar 5 Laser Warnings & Safety Fusion FX Bar 5 Laser Warnings & Safety
NON-INTERLOCKED HOUSING WARNING
The Fusion FX Bar 5 contains high power laser devices internally. Do
not open the laser housing, due to the potential exposure to unsafe
levels of laser radiation. The laser power levels, if the unit is opened,
can cause instant blindness, skin burns and res.
STOP AND READ ALL LASER SAFETY DATA
OPERATION INSTRUCTIONS AND LASER SAFETY
The light source emitted from this product can potentially cause eye
injury if not set up and used properly. The light source emitted from
a laser is very dierent from any other light sources with which you
may be aware of. Laser light is thousands of times more concentrated
than any light from any other kind of light source. This concentration
of light can cause instant eye injuries, primarily by burning the retina
(the back of your eyeball contatining cells that are sensitive to light).
Even if you cannot feel “heat” from a laser beam, it can still potentially
injure or blind you or your audience. Even very small amounts of laser
beam light are potentially hazardous even at long distances. Laser
eye injuries can be sustained faster than you can blink.
Do not think that because this laser splits the laser beam into hun-
dreds of beams and that the laser beam is scanned out in high speed,
that an individual laser beam is safe for eye exposure. This laser uses
dozens of milliwatts of laser power (Class 3B levels internally) before
it splits into multiple beams (Class 3R levels). Many of the individual
beams are potentially hazardous to the eyes.
Do not that because the laser light is moving, it is safe. This is not
true. Nor, do the laser beams always move. Since eye injuries can
occur instantly, it is critical to prevent even the smallest possibility of
any direct eye exposure. In the laser safety regulation, it is not legal
to aim Class 3R lasers in areas which people can get exposed. This is
true even if it is aimed below people’s faces, such as on a dance oor.
Do not operate the laser without rst reading and understanding
all safety and technical data in this manual.
Always set up and install all laser eects so that all laser light is at
least 3 meters (9.8 feet) above the oor on which people can stand.
After setting up, and before public use, test laser to ensure proper
function. Do not use if any defect is detected. Do not use if laser
emits only one or two laser beams rather than dozens/hundreds, as
this could indicate damage to the diraction grating optic, and could
allow emission of higher laser levels above Class 3R.
Do not point lasers at people or animals. Never look into the laser
aperture or laser beams.
Do not point lasers in areas in which people can potentially get
exposed, such as uncontrolled balconies, etc.
Do not point lasers at highly reective surfaces, such as windows,
mirrors and shiny metal. Even laser reections can be hazardous.
Never point a laser at aircraft, this is a federal oense.
Never point un-terminated laser beams into the sky.
Do not expose the output optic (aperture) to cleaning chemicals.
Do not use laser if the laser appears to be emitting only one or two
beams.
Do not use the laser if the housing is damaged, the housing is open,
or if the optics appear damaged in any way.
Never open the laser housing. The high laser power levels inside of
the protective housing can start res, burn skin and will cause instant
eye injury.
Never leave this device running unattended.
The operation of a class 3R laser show is only allowed if the show
is controlled by a skilled and well- trained operator, familiar with the
data included in this manual.
The legal requirements for using laser entertainment products vary
from country to country. The user is responsible for the legal require-
ments at the location/country of use.
Always use proper lighting safety cables when hanging lights and
eects overhead.
