QUICK START GUIDE

VARIA--ACS80F 8”Fixed Tabletop Stand

VARIA--ACS100F

10.1” Fixed Tabletop Stand

Overview

The Varia -Fixed Tabletop stands are designed for 8” VARIA80 & 10.1” VARIA-100

Touch Panels, -and give them a sturdy & stylish fixedangle tabletop solution

that’s reminiscent of AMX’s Modero touch panel family.

FIG. 1 Varia Touch Panel on Fixed Tabletop Stand

Model Availability & Compatibility

FIXED TABLETOP STANDS

VARIA-- ACS80F

(AMX- UMT0801)

VARIA- -1 80Touch Panel (AMXUTP081)

VARIA-- ACS100F

(AMX- UMT1001)

VARIA--1 100 Touch Panel (AMXUTP101)

V--1 ARIA100N Touch Panel (AMXUTP101N)

Other Models a Avilable

ANGLE- SELECTTABLETOP STANDS

VARIA--A ACS810

(AMX-) UMT8111

V--) ARIA80 Touch Panel (AMXUTP0811

V-- ARIA100 Touch Panel (AMXUTP1011)

V-1-ARIA00N Touch Panel (AMXUTP1011N)

VARIA--1A ACS50

(AMX- UMT1511)

V-15- ARIA0 Touch Panel (AMXUTP1511)

V-15- ARIA0N Touch Panel (AMXUTP1511N)

Installation

Varia Fixed Tabletop Stands are easily installed with the supplied hardware and

a Philips- head screwdriver.

1.Place the panel face- down on a soft cloth, andorient the panel so

that the top of the touch panel is closest to you.

FIG. 2 Varia Touch Panel, rear

2.If they are installed, remove two screws from the lower back cover.

Screw L ocations

FIG. 3 Rear cover screws, if installed

3.Place your thumbs push the on the rectangular access holes, and

lower cover away from you. The lower cover can then be placed

aside; it is not used with the Fixed Tabletop Stands.

FIG. 4 R ear coverremoval

4.Rotate the panel back around so the bottom is closest to you.

5.On the tabletop stand, remove the black plastic cover by sliding it

away from the aluminum base. It is held on by magnets. Then

unscrew the rubber pads from the base.

6.Install the aluminum base on the back o the touch panel.

Note:In most circumstances, the networking cable can be routed in

after base installation. However, category cablebulky s h witstrain

relief and/or hoods over the RJ-45 connector may need to be installed

before the aluminum base.

FIG.5 Fixed Tabletop Stand, aluminum base, underneath

7.Attach the base with the four (4) supplied screws.

Top

Top
