Quick Start Guide

First-Time Use / Admin Mode Setup

Aegis Padlock DT

There are two ways to establish a User PIN: Admin-generated

while in Admin Mode, and User-generated while Padlock DT is

placed in User Forced Enrollment State.

ADMIN-GENERATED USER PIN

1. Enter the Admin Mode by pressing and holding + 0 for ve

seconds (REDLED will blink.) Enter the Admin PIN and press

(BLUELED will glow solidly.)

2. Press and hold

+ 1 until the BLUELED glows solidly and the

GREENLED starts blinking.

3. Enter the PIN to be used as your User code and press .

(BLUE

LED will turn off and GREEN LED will blink 3 times by itself,

then will continue blinking as BLUE LED resumes glowing

solidly)

4. Quickly re-enter that same PIN once more and press

.

(If the PIN was successfully added, BLUE LED will turn off,

GREEN LED will illuminate for a second or two and then will

turn off, followed by the BLUE LED glowing solidly indicating

that the key has returned to Admin Mode. If PIN is unaccept-

able or the second entry doesn’t match the rst, REDLED

will ash three times, followed by solid BLUE / Blinking GREEN

LEDs.

NOTE:

if you are using the Aegis Congurator (sold separately) to set up your

Padlock DT, rst ensure that the device to be congured has the “congurable” logo

on the belly label.

Also, DO NOT perform the following Manual Admin and USER PIN SETUP

steps below; The Aegis Congurator will only recognize devices in their factory “out of box” state or

devices that have been completely reset.

Each Aegis Padlock DT is shipped without a preset Personal Identication Number (PIN.) To prepare the Key for

use, the user must rst establish an Admin PIN that is between 7 and 16 digits in length. PINs cannot contain all

consecutive numbers or all the same numbers (e.g. 123456789, 987654321 or 11111111, 22222222, etc.This

Admin PIN is used to set the Secure Key’s various Admin features and also serves as the rst of two User PINS

for the Secure Key’s standard operation.

To Set Up the Admin PIN:

1. Plug the Padlock DT into a powered USB port. (BLUE and GREEN LEDs will glow solidly, indicating no Admin

PIN has been established.)

2. Press + 9 simultaneously. (BLUE LED will glow solidly and GREEN LED will blink.)

3. Enter the PIN to be used as your Admin code and press

(If PIN is accepted, BLUE LED will turn off

momentarily and GREEN LED will blink 3 times by itself, then will continue blinking as the BLUE LED glows

solidly.)*

4. Quickly re-enter that same PIN once more and press

(BLUE LED will turn off momentarily and GREEN

LED will illuminate for one second until replaced by the BLUE LED glowing solidly, indicating that the Admin

PIN has been set and the Padlock DT is in Admin mode, ready to add another User PIN [see reverse] or for

setting up features.)

5. To exit the Admin mode, press

(RED LED will glow solidly) or wait 30 seconds and then Padlock DT will

return to standby mode.

6. If no additional users or Admin features are to be enabled, your Padlock DT setup is now complete and ready

for use.

CONFIGURABLE

Adding a New User PIN
