Seite 1/1
Aqara Home App
+
Hub
LED
OFF
ON
Max 8 A (Resistive Load)
P oduc Name
XXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXX
L1L2L
N
Screen
Button
Double-click quickly and then long-press for 5 seconds
to restore factory settings
Quick press 3 times: Confirm that the hub is within
acceptable distance
Note: For the Four-button version, only the two buttons on the le are relays. The other buttons are
wireless switches,and need to be configured on the App.
Manufacturer: Lumi United Technology Co., Ltd.
Address: Room 801-804, Building 1, Chongwen Park, Nanshan iPark, No. 3370,
Liuxian Avenue, Fuguang Community, Taoyuan Residential District, Nanshan District,
Shenzhen, China.
Online Customer Service: [http://www.aqara.com/support](http://www.aqara.com/-
support)
Email: support@aqara.com
A smart 2-channel with-neutral wall switch with four configurable buttons, which
provides different themes, icons, or texts to clearly showcase the function of each
button, so users can easily identify and control the corresponding light or appliance
without guessing. With power monitoring and Matter over Bridge support, it expands
energy-efficiency but also accessibility for users.
Effective distance verification: Quickly short press any button on the switch 3 times, and
the hub will emit a prompt tone, indicating that the device and the hub can communicate
effectively.
*This product requires a Zigbee3.0 hub to function.
*If adding fails, please move the hub closer to the product and try again aer powering on.
Product Introduction
1. Please add a hub to the App according to the hub’s manual;
2. Open the App, click "+" in the upper right corner of the homepage, enter the "Add
Device (Accessory)" page, and select Display Switch V1 EU, and follow the instructions;
Display Switch V1 EU
Model: WS-K02D
Dimensions: 86*86*42.2 mm (3.39 × 3.39 × 1.66 in.)
Operating Temperature: -10°C ~ 40°C (14°F ~ 104°F)
Wireless Protocols: Zigbee, Bluetooth
Operating Humidity: 0 ~ 95% RH, no condensation
Electrical Rating: 200 - 240 VAC, 50/60 Hz, Max 8 A (Resistive Load), µ
What is in the Box: Display Switch V1 EU × 1, User Manual × 1, Compliance Statement × 1,
Screw Kit × 2
If you have any other questions about this product, you can find more product
information on the following website:
https://store-support.aqara.com/products/display-switch-v1-eu/
Quick Setup
Product Specifications
FAQ
1. The installation of this product involves strong electric currents, and must be installed
by professionals in accordance with electrical specifications and product instructions;
2. This product is for indoor use only. Do not use it in a humid environment or outdoors.
3. Avoid excessive moisture. Do not spill water or other liquids on this product.
4. Do not place this product near heat sources;
5. Do not attempt to repair this product by yourself. Repairs should be performed by
authorized professionals.
6. Do not scratch the display screen with sharp objects.
Warnings
1.Before installation, please ensure that
the main power switch is switched off
at the circuit breaker.
3. Use the screwdriver to loosen the terminal screws on the back of the switch. Connect
the live wire to the L terminal. connect the neutral wire to N terminal ,and connect the
load (light) wire to the L1 and L2 terminal, and aer confirming that the wiring is
correct, tighten the terminal screws. Maximum load is 8 Amps (Resistive Load)
4. Use the included screws to secure the switch to the wall junction box and snap on the
panel. Ensure you follow the panel's snap-on installation instructions carefully.
5.Turn on the main power switch and press
the le button(wired to load) to turn on
the lights, if the lights operate normally,
the switch is working properly.
Installation Methods
2. Use a Phillips head screwdriver to pry open the switch panel;
Display Switch V1
EN
*Do not exceed 0.7N·m of screw torque.
