Electric Pump

User Manual

Model: Airbird C4

Thank you for purchasing this portable air pump. Please

read this user manual carefully before using the product and

keep it properly for reference in the future.

•Do not leave during inflation.

•Please do not put the electric pump near inflammable and

explosive items.

•Try to avoid moist,sediment invasion and fall.

•Do not store the product in a place that is too cold, too hot or

too humid.

•Built-in lithium battery, Do not throw the product into the fire or

throw it away casually.

•Keep the product away from the children.

Power on

Long press the power button for 3

seconds to power on.

Power o

Long press the power button for 3

seconds to power o.

Type-C charging input 5V/2A. Connect

the charging cable to the pump and

the power adapter (you need to buy

your own) to charge the pump.

Power indicator bar in charging state:

Indicator bar flashing: charging When

the indicator bar is long bright: it is full

Tips: Do not use the pump during

charging.

Use a ball needle when inflating

basketball, football and other balls.

Inflation: press the ball needle and

the Schrader Valve interface tightly

and insert into the ball to inflate.

When the air pump is on, after

the air hose is connected to the

inflation pressure detection object,

the figure in the upper part of the

air pump display is the measured

pressure value.

Press the working mode key to select

5 inflatable scene modes, as:

Actual

Pressure

Preset

Pressure

Mountain bikes, electric bikes,

motorcycles, cars will be equipped with

Schrader Valve.

Inflation: Connect the Schrader Valve

with the Schrader Valve interface on

the high pressure air hose to inflate.

Road bikes and some mountain bikes

need to use Presta Valve adapters

when inflating.

1. Connect the Presta Valve adapter

with the Schrader Valve interface on

the high pressure air pipe.

2. Unscrew the Presta Valve cap of

the tire.

3. The Presta Valve can be connected

with the converter to inflate.

Use Schrader Valve first to attach

the Dunlop Valve.

Schrader Valve (+Dunlop Valve

Presta Valve Adapter

Ball Needle

Dierent indicator color on the power

indicator bar show dierent power

Green: 70%-100%

Yellow: 30-70%

Red: 5%-30%

Red Flash: below 5% In low power

state, need to charge before use.

Under the power on state, press the

Start/Stop button to start inflation

and automatically stop inflation when

the preset pressure value is reached.

1. Power on and o

4. Charging Type

5. Connect the air hose to the air nozzle

2. Battery Indicator

3. Start/Stop Button

Portable Electric PumpPrecautionsUser Guide

6. Check the air pressure

7.Application scenario switch

Packing list

Specification

1 x Air pump1 x Ball needle

1 x Schrader Valve air hose1 x Dunlop Valve

1 x Type-C Cable1 x Presta Valve

1 x Storage Bag1 x Manual

Scene

Mode

Reference Default

Values

Adjustable

Range

Car35PSI2-65PSI

Motorcycle40PSI2-55PSI

Bicycle38PSI2-150PSI

Ball8PSI2-15.0PSI

Custom36PSI2-150PSI

Product Dimension68×48×154mm

Product Net Weight451g

Max Air Pressure10,3 BAR - 150 PSI

Working Temperature-10~45°C

Battery Capacity2x2000 mAh / 7.4V / 14.8Wh5V

Input Parameter2A

USB Output5V-2A

[a]Actual Pressure

[b] Unit Display

[c]Preset Pressure

[d]Battery Indicator

[e]Mode Display

[f]Preset +

[g] Preset-

[h]Mode/Tire Forward

[i]Mode/Tire Backward

[j]Power Switch/ Start-Stop

[k]LED Light Switch

[l] Type-c Input /

output

[o] USB

Output

[p] Air Hose

Interface

[m] LED Light

[n] Air Hose

Storage

Power on

Nozzle

type

Nozzle

type

Nozzle

type

Power o

Inflation

connector

Inflation

connector

Inflation

connector

8
