INSTALLATION INSTRUCTIONS

TXV Coils

EDM, EDD, EDA

These instructions must be read and understood completely before attempting installation.

It is important that the Blower and Duct System be properly sized to allow the system to operate at full capacity. Poorly

designed systems will not give satisfactory cooling or economy. They may even shorten the service life of the compressor

in the outdoor unit.

DANGER, WARNING, CAUTION, and

NOTE

The signal words DANGER, WARNING, CAUTION,

and NOTE are used to identify levels of hazard serious-

ness. The signal word DANGER is only used on prod-

uct labels to signify an immediate hazard. The signal

words WARNING,CAUTION, and NOTE will be used

on product labels and throughout this manual and other

manuals that may apply to the product.

DANGER− Immediate hazards which will result in se-

vere personal injury or death.

WARNING − Hazards or unsafe practices which could

result in severe personal injury or death.

CAUTION −Hazards or unsafe practices which may

result in minor personal injury or product or property

damage.

NOTE − Used to highlight suggestions which will result

in enhanced installation, reliability, or operation.

Signal Words in Manuals

The signal word WARNING is used throughout this manu-

al in the following manner:

The signal word CAUTION is used throughout this manual

in the following manner:

Signal Words on Product Labeling

Signal words are used in combination with colors and/or

pictures on product labels.

WARNING

Safety Labeling and Signal Words

!

CAUTION

WARNING

!

TABLE OF CONTENTS

Installation2 − 4..................................

Condensate Drain4 − 5...........................

Waste Line Connection5..........................

Refrigerant Line Connections6....................

Refrigerant Metering Device7.....................

Check and Adjust Airflow7 − 8.....................

Start−Up Procedure9............................

R−410A Quick Reference Guide9..................

!

WARNING

ELECTRICAL SHOCK HAZARD

Failure to turn off electric power could result in

personal injury or death.

Before installing or servicing system, turn off main

power to the system. There may be more than one

disconnect switch, including accessory heater(s).

INSTALLATION

EDA loose coils are shipped with a metal collar plate

approximately the same size as the drain pan. The collar

plate must be installed between the drain pan and the

furnace or air handler cabinet to prevent condensation inside

the cabinet. Position the collar plate as shown in Figure 1,

with the flanges pointing down, towards the furnace or air

handler cabinet. Size the plenum or fabricate spacers to seal

against the outside of the collar and prevent air bypass.

UNIT OR PROPERTY DAMAGE HAZARD

Failure to follow this caution may result in property

damage.

Take precautions to ensure Aluminum tubes do not

come in direct contact or allow for condensate run

off with a dissimilar metal. Dissimilar metals can

cause galvanic corrosion and possible premature

failure.

CAUTION

!
