Arecont Vision MegaBall™ Installation Manual
1 | P a g e
MegaBall™ Wall Mount Version (-W) Installation Manual
A. Arecont Vision MegaBall™camera with
wall mount (indoor use only)
Inside the box:
B. CD with AV100 oftware and s user
manuals (license key required for
recording)
C. Mounting template
D. (3Pack of three ) wood screws and three
(3) dry wall anchors
E. -One double sided hex key (fixed focal lens
version only)
F. -K Security L ey
• #1 Phillips head screwdriver
Not included but needed:
Image 1
Mounting the Camera:
1. Remove the camera and hardware from the
box.
2. Using the mounting template, prepare the
mounting surface for camera installation.
3. Plug the Ethernet cable into the MegaBall™
PoE female RJ45 connector. (Image 2)
NOTE: If the camera will be powered via PoE,
please skip to step 5.
Image 2
4. If the camera will be powered by an AC or DC
power supply, connect external power with
pigtail cable connector.
NOTE 1: Ensure that the polarity of the DC
input on the camera matches the way that the
wires are installed in the connector shown in
Image 2.
NOTE 2: AC power does not have polarity.
5. oAlign the holes n the camera wall mount with
the prepared holes on the mounting surface.
Attach the camera to the mounting surface
with the wood screws or any other hardware
suitable for the mounting surface.
F
E
C
A
D
B
Digital In
Digital Out
Auxiliary Power
PoE RJ45
Arecont Vision MegaBall™ Installation Manual
2 | P a g e
6. To adjust the camera tilt, pan or z-axis (yaw),
loosen the ring on the wall mount bracket as
shown in Image 3 then adjust as necessary
and retighten the ring.
Adjusting the T -ilt, Pan, Z Axis (yaw):
Image 3
NOTE : The 3-axis bracket allows 360°
camera body rotation, 90° tilt and 360°
bracket rotation y installation in any for eas
location. (Image 4)
Image 4
CAUTION: Adjusting the camera without
loosening the bracket ring may result in
scratches on the bracket joint. Incorrect
installation under practices are not covered
warranty!
7. model For - the vari focal , adjust the focus, iris
and field of view using the provided Security
L-K ( ) ey Image 1F as shown in Image 5.
Adjusting the Focus, Iris and Field of View:
Image 5
8. model For - the fixed focal , adjust the focus by
loosening the t wo set screws on the front shell
as shown in Image 6 using supplied double
sided hex key (Image 1E) A. djust the lens
adapter to focus the camera as shown in
Image 7. Retighten the set screws once
focusing is complete.
Image 6 Image 7
90
°
360
°
360
°
Iris
Focus
Bracket Ring
Zoom
Set Screws
