ROG Rapture GT-BE19000
WiFi 7 Tri-band Gaming Router
Quick
Start Guide
Hardware Explanations
Gain Another 10GE LAN Port
DC Power adapterDC Output: +19.5V with max 3.33A current
+12V with max 5A current
Operating Temperature0~40
o
CStorage0~70
o
C
Operating Humidity50~90%Storage20~90%
Specications:
RouterSetup Steps
Prepare your Modem
01
1
Unplug the power of cable / DSL modem.
5
Launch App and follow [App]ASUS Router
the instructions to complete the setup.
Modem back
Unplug
Install your Router
02
1
Plug the adapter into the DCIN port, and press
the Power switch.
2
Connect your modem to the 10GE WAN port at the back side of
the router with the network
cable provided.
3
Power on the modem. Plug
modem to the power outlet
and power on.
Modem back
4
Check the modem LED lights to ensure the connection is active.
If you are using DSL for internet,
you will need your username /
password from your Internet
service provider (ISP) to properly
configure your router.
Modem front
– Or via web browser
3
Connect your PC to a LAN (LAN2~6) port [Wired]
at the back side of the router using an additional
network cable.
[Wireless] Connect to the network with default SSID
shown on the product label on the back side of your
router “ASUS_XX”.
4
Open a web browser.[Wired / Wireless]
You will be redirected to the ASUS Setup Wizard. If not, navigate to
http://www.asusrouter.com
Follow the instructions to complete the setup.
http://www.asusrouter.com
– Via app
3
On your iOS or Android mobile device, go [App]
to the app store, search for , and ASUS Router
download the app.
4
On your iOS or Android mobile device, tap , [App]Settings > Wi-Fi
connect to the default network SSID shown on the product label
on the back side of the router. Or scan the code on the product
label to connect the default network SSID.
* refers to the last two XX
digits of 2.4GHz MAC
address. You can find it
on the label on the back
of your router.
_
2
The Power LED will light up when the hardware is ready.
Power switch
2.5GE LAN2-4 ports
Power (DCIN)
port
Reset button
1GE LAN5 port
10GE WAN/LAN1 port
WPS button
* If no 6GHz SSID is displayed, please check whether your OS and client device are fully licensed to support the newly
released 6GHz band. You can check with your OS and client device provider for Wi-Fi 6E / Wi-Fi 7 driver release
schedule.
USB 3.0 port
USB 2.0 port
LED button
Connect to the 2.5GE WAN port
Connect the modem to the 2.5GE WAN port with a
network cable.
Login and Connect
1
Select “Manual Setting”. [ASUS Setup Wizard]
2
Select “2.5G WAN”, then follow the instructions [ASUS Setup Wizard]
to complete the setup of SSID and login information.
Set up 2.5GE WAN connection to release another 10GE LAN Port
01
– Under factory defaults
10GE LAN LED
2.5GE/1GE LAN LED
10GE/2.5GE WAN
(Internet) LED
Power LED
6GHz/5GHz/2.4GHz
WiFi LEDs
2.5GE WAN/LAN1 port
E23490
10GE LAN6 port
WPS LED
