Seite 1/12
Owner’s Manual
TSD-RL21
2x1 Mic/Line Mixer
AtlasIED.com – 1 –
Specifications are subject to change without notice.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
TSD-RL21
2x1 Mic/Line Mixer with Remote Level
Owner’s Manual
TSD-RL21
2x1 Mic/Line Mixer
AtlasIED.com – 2 –
Specifications are subject to change without notice.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Description
The versatile AtlasIED TSD-RL21 2x1 mic/line mixer is ideal for applications where paging, public
address, and BGM music is required.
Use as a standalone remote mixer or in conjunction with AtlasIED power amplifiers in applications
such as conference center meeting rooms, football stadiums, gymnasiums, retail/hospitality or other
areas requiring versatile, multi source mix control.
Channel one may be configured via rear panel dipswitch to accommodate mic or line level while
channel two features a stereo summing RCA line level input. Both inputs are adjustable by front
panel controls with removable knobs, which may be easily replaced by security covers to prevent
tampering.
The remote level control feature allows use of the AtlasIED AAVC-10K (or equal) decorative wall
plate control for convenient remote adjustment of either the entire mix bus or RCA input 2 only (the
typical BGM input).
The TSD-RL21 is part of a full line of AtlasIED Time Saving Devices. These compact
(1.5" x 4" x 2.75") units are designed to solve some of the common audio system problems in the
easiest and in the most efficient and cost-effective way. All models are made from high quality
components and include removable individual I/O connectors for quick and precise wiring, separate
ground terminals for all I/Os assuring secured connections, and removable level controls that can be
replaced with tamper-proof security covers.
Features
• Selectable Balanced Mic or Line Input
• RCA Actively Summed Input
• High Gain Mic Input 50dB
• Balanced Line Output
• Input Peak & Signal Indicator LEDs
• Remote Level Control Assignable to the
Mixed Signal or to a BGM Source
• High Gain Output for Driving Long
Balanced Lines
• Cable Management System
• MultipleMountingCongurations
• Separate Ground Connections
• Removable Phoenix Style I/O Connectors
• Meets Energy Star™ Standards
• Compact Chassis Design
Audio Applications
• Mixer
• Mic Preamp
• Line Preamp
• Stereo Summing Preamp
• Line Drive
• Remote Level Control
Installation
• Churches
• Restaurants
• Sports Bars
• Schools
• Industrial Facilities
• House of Worship
