• Ideal for acoustic guitar, overheads, piano and group vocals

• Condenser design for studio-quality vocal and instrument

applications

• Excels in high-SPL applications

•

Extended response for smooth, natural sonic characteristics

• Low-mass element for superb transient response

• Corrosion-resistant gold-plated XLRM-type connector

•

Rugged design and construction for reliable performance

• Cardioid polar pattern reduces pickup of sounds from the sides

and rear, improving isolation of desired sound source

The AT2021 is intended for use in professional applications where

remote po

wer is available. It requires 48V DC phantom power,

which may be provided by a mixer or console, or by a

separate, in-line source such as the Audio-Technica AT8801 single-

channel or CP8506 four-channel phantom power supplies.

Output from the microphone's XLRM-type connector is low

impedance (Lo-Z) balanced. The signal appears across Pins 2 and

3; Pin 1 is ground (shield). Output phase is “Pin 2 hot” - positive

acoustic pressure produces positive voltage at Pin 2.

To avoid phase cancellation and poor sound, all mic cables must be

wired consistently:

Pin 1-to-Pin 1, etc.

Avoid leaving the microphone in the open sun or in areas where

temperatures exceed 110° F (43° C) for extended periods.

Extremely high humidity should also be avoided.

AT2021 SPECIFICATIONS

†

ELEMENT Fixed-charge back plate

permanently polarized condenser

POLAR PATTERN Cardioid

FREQUENCY RESPONSE 30-20,000 Hz

OPEN CIRCUIT SENSITIVITY –39 dB (11.2 mV) re 1V at 1 Pa*

IMPEDANCE 250 ohms

MAXIMUM INPUT SOUND LEVEL 145 dB SPL, 1 kHz at 1% T.H.D.

NOISE

19 dB SPL

DYNAMIC RANGE (typical) 126 dB, 1 kHz at Max SPL

SIGNAL-TO-NOISE RATIO

75 dB, 1 kHz at 1 Pa*

PHANT

OM POWER

48V DC

, 2 mA typical

REQUIREMENTS

WEIGHT (less accessories) 2.9 oz (83 g)

DIMENSIONS 4.00" (101.5 mm) long,

0.83" (21.0 mm) maximum body

diameter

OUTPUT CONNECTOR Integral 3-pin XLRM-type

ACCESSORIES FURNISHED Stand clamp; soft protective pouch

†

In the interest of standards development, A.T.U.S. offers full details on its test

methods to other industry professionals on request.

*1 Pascal = 10 dynes/cm

= 10 microbars = 94 dB SPL

Typical, A-weighted, using Audio Precision System One.

Specifications are subject to change without notice.

Audio-Technica U.S., Inc., 1221 Commerce Drive, Stow, Ohio 44224

Audi

echnica Limited,

Old Lane, Leeds L

1 8AG England

www.audio-technica.com

AT2021

12" or more on axis

LEGEND

Frequency in Hertz

Frequency Response

Response in dB

SCALE IS 5 DECIBELS PER DIVISION

Polar Pattern

200 Hz

LEGEND

5 kHz

1 kHz

8 kHz

SMALL-DIAPHRAGM CARDIOID

CONDENSER MICROPHONE

Produktspezifikationen

Marke:	Audio-Technica
Kategorie:	Mikrofon
Modell:	AT2021
Produktfarbe:	Schwarz
Übertragungstechnik:	Kabelgebunden
Typ:	Bühnen-/Auftrittsmikrofon
Geräteschnittstelle:	mini XLR (3-pin)
Gehäusematerial:	Messing
THD, totalklirren:	1 %
Mikrofon-Frequenz:	30 - 20000 Hz
Mikrofon-Empfindlichkeit:	-39 dB
Mikrofon-Eingangsimpedanz:	250 Ohm
Ausrichtung des integrierten Mikrofons:	Kardioide
Tragetasche:	Ja
Anzahl enthaltener Produkte:	1 Stück(e)
Microphon Abmessungen (D x H):	21 x 101.5 mm
Mikrofongewicht:	83 g
Gewährleistungsfrist:	2 Jahr(e)
Stimmenmagnetspuele Typ:	Vorpolarisierter Kondensator
Mikrofonhalter:	Ja
Mikrofon Signal-to-Noise Ratio (SNR):	75 dB
Maximaler Schalldruckpegel (1kHz):	145 dB
Mikrofon Dynamikbereich:	126 dB
