SCALE IS 5 DECIBELS PER DIVISION

Polar Pattern

200 Hz

LEGEND

5 kHz

1 kHz

8 kHz

12" or more on axis

LEGEND

Roll-off

Frequency in Hertz

Frequency Response

Response in dB

• Ideal for sax, toms, brass and percussion

• Excels in high-SPL applications

• Perfect for active stage performances

• Extended frequency response captures subtle nuances of the

performance

• UniMount

clip permits accurate positioning, provides shock

resistance and protects element

• Corrosion-resistant contacts from gold-plated XLRM-type

connector

• Cardioid polar pattern reduces pickup of sounds from the sides

and rear, improving isolation of desired sound source

The PRO 35 is intended for use in professional applications where

remo te powe r i s av aila ble. It requ ires 11 V to 52V DC

phantom power, which may be provided by a mixer or console, or

y a separate, in-line source such as the Audio-Technica AT8801

single-channel or CP8506 four-channel phantom power supplies.

An integ

ral 80 Hz high-pass filter provides easy switching from a flat

frequency response to a lo

w-end roll-off. The roll-off position

reduces the pickup of low-frequency ambient noise (such as traffic,

air-handling systems, etc.), room reverberation and mechanically

coupled vibr

ations.

Output from the power module’s XLRM-type connector is low

impedance (Lo-Z) balanced. The signal appears across Pins 2 and

Pin 1 is ground (shield). Output phase is “Pin 2 hot” – positive

acoustic pressure produces positive voltage at Pin 2.

o avoid phase cancellation and poor sound, all mic cables must be

wired consistently:

Pin 1-to-Pin 1, etc.

oid lea

ving the microphone in the open sun or in areas where

temperatures exceed 110° F (43° C) for extended per iods.

Extremely high humidity should also be a

oided.

PRO 35 SPECIFICATIONS

†

ELEMENT Fix

ed-charge back plate

per

manently polarized condenser

POLAR P

ATTERN

Cardioid

FREQUENCY RESPONSE 50-15,000 Hz

LOW FREQUENCY ROLL-OFF 80 Hz, 18 dB/octave

OPEN CIRCUIT SENSITIVITY –

45 dB (5.6 mV) re 1V at 1 Pa*

IMPED

ANCE

250 ohms

MAXIMUM INPUT SOUND LEVEL 145 dB SPL, 1 kHz at 1%

THD

YNAMIC RANGE

(typical)

115 dB, 1 kHz at Max SPL

SIGNAL-T

O-NOISE RATIO

64 dB

,1 kHz at 1 Pa*

PHANTOM POWER REQUIREMENTS 11-52V DC, 2 mA typical

SWITCH Flat, roll-off

WEIGHT (less cab

le and accessories)

MICR

OPHONE

0.3 oz (8 g)

POWER MODULE 2.9 oz (81 g)

DIMENSIONS

MICR

OPHONE

0.98" (25.0 mm) long,

0.40" (10.2 mm) diameter

WER MODULE

3.66" (92.9 mm) long,

0.74" (18.9 mm) diameter

OUTPUT CONNECT

Integ

ral 3-pin XLRM-type

(power module)

CABLE 6.0' (1.8 m) long (per

manently

attached to microphone),

0.10" (2.6 mm) diameter,

2-conductor

, shielded cable with

A3F-type connector

ACCESSORIES FURNISHED AT8418 UniMount

microphone

instr

ument mount; AT8538 power

module;

soft protective pouch

†

In the interest of standards development, A.T.U.S. offers full details on its test

methods to other industry professionals on request.

*1 Pascal = 10 dynes /cm

= 10 microbars = 94 dB SPL

Typical, A-weighted, using Audio Precision System One.

Specifications are subject to change without notice.

Audio-Technica U.S., Inc., 1221 Commerce Drive, Stow, Ohio 44224

Audi

echnica Limited,

Old Lane, Leeds L

1 8AG England

www.audio-technica.com

PRO 35

CARDIOID CONDENSER CLIP-ON

INSTRUMENT MICROPHONE

Produktspezifikationen

Marke:	Audio-Technica
Kategorie:	Mikrofon
Modell:	PRO35
Produktfarbe:	Schwarz
Übertragungstechnik:	Kabelgebunden
Energiequelle:	Gleichstrom
Typ:	Mobiltelefon/Smartphone-Mikrofon
Kabellänge:	1.8 m
Energieverbrauch:	21 mA
Mikrofon-Frequenz:	50 - 15000 Hz
Mikrofon-Empfindlichkeit:	-45 dB
Mikrofon-Eingangsimpedanz:	250 Ohm
Netzteiltyp:	Gleichstrom
Anzahl enthaltener Produkte:	1 Stück(e)
Arbeitsspannung:	11 V
Microphon Abmessungen (D x H):	10.2 x 25 mm
Tiefe (imperial):	0.4 "
Breite (imperial):	0.98 "
Mikrofon-Modus:	Verflüssiger
Höhe (imperial):	0.4 "
