ADS48

OVERVIEW

The Audix ADS48 is a wide range UHF antenna distribution system that combines up to

four wireless systems to be able to run off a single pair of antennas and power supply.

The ADS48 has an internal switching power supply which eliminates the need for the

individual DC power supplies normally needed for each receiver. RF signals are internally

amplified in order to compensate for any loss that may result from splitting the signal.

SUPPLIED ACCESSORIES

1 x ADS48 Antenna Distribution Unit with rack mount

2 x Antennas - (see photo A below)

1 x IEC power cable

4 x Power Jumper Cables to provide power to individual receivers - (see photo B below)

8 x BNC-to-BNC Coaxial Cables for pass through connection for up to

4 additional receivers (single or dual) - (see photo C below)

2 x Coaxial cables for front mounting antennas - (see photo D below)

UHF Antenna

Distribution System

SPECIFICATIONS

Frequency Range

470 - 900 MHz

RF Output Level (Gain)

0 dB d + or – 3 dB

Input Impedance

50 Ohm

Output Impedance

50 Ohm

Power Voltage

100 – 240 V AC 50 / 60 Hz

Output DC Voltage

+12 V DC, 800 mA maximum

Antenna Input DC Voltage

8 V, 150 mA maximum

Dimensions

19” (W) x 2” (H) x 10” (D)

480 mm (W) x 45 mm (H) x 250 mm (D)

Net Weight

16 oz / 2.15 kg

ABCD
