Seite 1/8
AX-AB-LX1
I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 7/16/20 INSTAX-AB-LX1
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip ties
TABLE OF CONTENTS
Amplifier locations ................................................2
Connections
-Lexus .....................................................................3
-Subaru ...............................................................3-4
-Toyota ................................................................ 4-7
Lexus/Subaru/Toyota Amplifier Bypass Harness
2012-Up
Refer to the following pages for the vehicle specific instructions for
wiring connections. Wiring connections vary per vehicle.
If it’s uncertain whether the vehicle contains a specific speaker or not,
test the wires with a tone generator, or check to see if the factory
wires are populated on the vehicle side. Alternatively, the wires can
be tested for impedance with a multimeter.
APPLICATIONS
Lexus
CT200H 2014-2017
ES300H 2013-2018
ES350 2013-2018
GS F 2016-Up
GS200T 2015-2017
GS300 2018-Up
GS350 2015-Up
GS450H 2013-Up
GX460
(9-spk. system) 2013-Up
IS350 (w/ NAV) 2013-Up
IS250 (w/ NAV) 2013-2015
IS F (w/ NAV) 2013-2014
IS200T 2016-2017
IS250C (w/ NAV) 2013-2015
IS300 2016-Up
IS350C (w/ NAV) 2013-2015
NX200T 2015-2017
NX300H 2015-2017
RC F 2015-2017
RC200T 2016-2017
RC300 2016-2017
RC350 2015-2017
RX350 2013-2017
RX450H 2013-Up
Subaru
Ascent 2019-Up
Crosstrek 2018-Up
Forester 2019-Up
Impreza 2017-Up
Legacy 2015-Up
Outback 2015-Up
Toyota
Avalon 2013-Up
Camry 2012-Up
Mirai 2016-Up
Highlander 2014-Up
Land Cruiser 2013-Up
Prius 2012-Up
RAV4 2013-Up
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
2
AMPLIFIER LOCATIONS
Lexus Years Amplifier Location
CT200H 2014-2017 Under passenger seat
ES300H 2013-2018 Under driver’s seat
ES350 2013-2018 Under driver’s seat
GS F 2016-Up Passenger side of trunk behind wheel-well
GS200T 2015-2017 Passenger side of trunk behind wheel-well
GS300 2018-Up Passenger side of trunk behind wheel-well
GS350 2015-Up Passenger side of trunk behind wheel-well
GS450H 2013-Up Passenger side of trunk behind wheel-well
GX460 (w/ 9-spk system) 2013-Up Under passenger seat
IS350 (w/ NAV) 2013-Up Passenger side of trunk behind wheel-well
IS250 (w/ NAV) 2013-2015 Passenger side of trunk behind wheel-well
IS F (w/ NAV) 2013-2014 Driver’s side of trunk behind wheel-well
Lexus Years Amplifier Location
IS200T 2016-2017 Driver’s side of trunk behind wheel-well
IS250C (w/ NAV) 2013-2015 Passenger side of trunk behind wheel-well
IS300 2016-Up Passenger side of trunk behind wheel-well
IS350C (w/ NAV) 2013-2015 Passenger side of trunk behind wheel-well
NX200T 2015-2017 Passenger side of trunk behind wheel-well
NX300H 2015-2017 Passenger side of trunk behind wheel-well
RC F 2015-2017 Passenger side of trunk behind wheel-well
RC200T 2016-2017 Passenger side of trunk behind wheel-well
RC300 2016-2017 Passenger side of trunk behind wheel-well
RC350 2015-2017 Passenger side of trunk behind wheel-well
RX350 2013-Up Center of the trunk on the floorboard
RX450H 2013-Up Passenger side of trunk on floorboard behind seat
Subaru
All Models 2015-Up Under passenger seat
Toyota
Avalon 2013-Up Under driver’s seat
Camry 2012-Up Under driver’s seat
Mirai 2016-Up Driver’s side of trunk behind wheel-well
Highlander 2014-Up Center console
Toyota
Land cruiser 2013-2018 Under driver’s seat
Land cruiser 2019 Center console
Prius 2012-2015 Under passenger seat
Prius 2016-2019 Under driver’s seat
Rav4 2013-Up Passenger rear quarter panel
3
REV. 7/16/2020 INSTAX-AB-LX1
CONNECTIONS
White Left Front Speaker (+)
White/Black Left Front Speaker (-)
Gray Right Front Speaker (+)
Gray/Black Right Front Speaker (-)
Green Left Rear Speaker (+)
Green/Black Left Rear Speaker (-)
Purple Right Rear Speaker (+)
Purple/Black Right Rear Speaker (-)
Green/White Left Front Door Woofer (+)
White/Red Left Front Door Woofer (-)
Brown/Yellow Right Front Door Woofer (+)
Brown/Blue Right Front Door Woofer (-)
Brown/White Center Channel Speaker (+)
Blue/Pink Center Channel Speaker (-)
Green/Orange Left Rear Deck Speaker (+)
Green/Red Left Rear Deck Speaker (-)
Black/Yellow Right Rear Deck Speaker (+)
Black/Green Right Rear Deck Speaker (-)
Lexus all models 2013-Up
• The , , , and Green/Purple Pink White/Blue
Yellow/Brown wires are for the subwoofer
speaker(s). Due to differences in applications
regarding these wires, these wires must to be
tested with a tone generator and phase tester
to verify the subwoofer wires, and also polarity.
Green/White Front Right Speaker (+)
White/Red Front Right Speaker (-)
Brown/Yellow Front Left Speaker (+)
Brown/Blue Front Left Speaker (-)
Pink Subwoofer 1 (+)
White/Blue Subwoofer 1 (-)
Brown/White Subwoofer 2 (+)
Blue/Pink Subwoofer 2 (-)
Yellow/Brown Rear Right Speaker (+)
Green/Purple Rear Right Speaker (-)
Blue Rear Left Speaker (+)
Blue/Black Rear Left Speaker (-)
Green/Orange Right Tweeter (+)
Green/Red Right Tweeter (-)
Black/Yellow Left Tweeter (+)
Black/Green Left Tweeter (-)
White Right Satellite Speaker (+)
White/Black Right Satellite Speaker (-)
Gray Left Satellite Speaker (+)
Gray/Black Left Satellite Speaker (-)
Green Center Channel Speaker (+)
Green/Black Center Channel Speaker (-)
Subaru Ascent 2019-Up
Blue Right Tweeter (+)
Blue/Black Right Tweeter (-)
Black/Yellow Front Left Speaker (+)
Black/Green Front Left Speaker (-)
White Front Right Speaker (+)
White/Black Front Right Speaker (-)
Gray Left Tweeter (+)
Gray/Black Left Tweeter (-)
Green Rear Left Speaker (+)
Green/Black Rear Left Speaker (-)
Purple Rear Right Speaker (+)
Purple/Black Rear Right Speaker (-)
Subaru Crosstrek 2018-Up / Impreza 2017-Up
