AX-MAZCAMAX-MAZCAM

REV. 8/28/18REV. 8/28/18© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

INSTALLATION INSTRUCTIONS

INSTALLATION INSTRUCTIONS

INTERFACE FEATURES

• Retains the factory backup camera to an aftermarket radio

• Allows an aftermarket camera to be added to the factory screen

INTERFACE COMPONENTS

• AX-MAZCAM harness

MazdaBackup Camera Retain/Add-On

2007-2015

MAZDA

CX-5 2013-2015

CX-7 2007-2012

CX-9 2007-2015

Mazda6 2011-2015

• Wire cutter • Crimping tool • Solder gun • Tape

• Connectors (example: butt connectors, bell caps, etc.)

APPLICATIONS

TOOLS REQUIRED

CAUTION!

All accessories, switches, climate controls panels, and especially air bag indicator lights must

be connected before cycling the ignition. Also, do not remove the factory radio with the key in the on

position, or while the vehicle is running.

KPNOWLEDGE IS OWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and spected re

mobile electnics school in our industry.ro

Log onto www.installerinstitute.com or call

800-354-6782 for mo information and take steps re

toward a better tomorrow.

®

Metra recommends MECP

certified technicians

Connections to be made

The AX-MAZCAM can be connected two different ways

To retain the factory backup camera to an aftermarket radio:

• Connect the wire to chassis ground, and also to the wire of the AX-CAM6V.BlackBlack

• Connect the Yellow wire labeled "Camera Power 6V" to the AX-CAM6V (sold separately)* .

• Connect the

male

Yellow RCA jack to the rear camera input of the aftermarket radio.

• Connect the reverse wire from the aftermarket radio, to the reverse signal in the vehicle.

* It is highly recommended to use the AX-CAM6V (sold separately) to provide the camera with

the proper voltage.

To allow an aftermarket camera to be added to the OEM screen:

• Connect the

female

Yellow RCA jack to the aftermarket camera.

• Tape off and disregard the following (2) wires, they will not be used in this application;

BlackYellow,

IMPORTANT

If you are having difficulties with the installation of this product, please call our Tech Support

line at 1-800-253-TECH. Before doing so, look over the instructions a second time, and make

sure the installation was performed exactly as the instructions are stated. Please have the

vehicle apart and ready to perform troubleshooting steps before calling.
