Seite 1/8
AXDSPX-A2B2
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 2/13/24 INSTAXDSPX-A2B2
INTERFACE COMPONENTS
Ford Select Models 2018-Up* A2B Data Interface
with Amplifier Bypass Harness & DSP
• AXDSPX-A2B2 interface
• AXDSPX-A2B2 harness
• Amplifier bypass harness
• Radio T-Harness
• AXBK-1
• A2B-EXT
• Bass Knob
• Extension Cable
For refer to Enter the year, make, and model of the vehicle in theDash Disassembly Instructions, metraonline.com. Vehicle Fit Guide for Radio Install kits.
*Visit for current application list. axxessinterfaces.com
TABLE OF CONTENTS
Interface Features 2 ..................................................
Things To Know About The AXDSP 3-4 ...................
Connections 5-6 ........................................................
Quick Setup Steps: AXDSP-XL App 7 .......................
LED Feedback 8 .........................................................
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape
• Wire cutter
• Zip-ties
Google Play Store
Apple App Store
iOS 12.1 or higher
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. Ensure that all installation
connections, especially the air bag indicator lights,
are plugged in before reconnecting the battery or
cycling the ignition to test this product.
NOTE: Refer also to the instructions included with
the aftermarket radio.
Metraonline.com
Visit and for harness and interface options.MetraOnline.com Axxessinterfaces.com
2
AXDSPX-A2B2 INTERFACE FEATURES
INTERFACE FEATURES
• Designed for B & O A2B amplifiers
• A2B data interface w/AXDSP-X (digital signal processor) built-in
• Includes an amplifier bypass harness
• Retains factory chimes including parking sensor chimes
• Retains SYNC voice prompts
• Chimes and voice prompts go through the aftermarket amplifier and/or cluster
• Selectable 31 Band graphic EQ or 5 Band Parametric EQ
• 10 individually assignable outputs
• Independent equalization on each of the 10 outputs
• Independent high pass, low pass, and bandpass filters
• Each channel can be delayed independently up to 10ms
• Clipping detection and limiting circuits
•
Settings adjusted via Bluetooth® in a smart device application (tablet
or mobile phone),
compatible with both Android and Apple devices
• Read, write, and store configurations for future recall
• Password protect feature available in the mobile app
• Micro-B USB updatable
3
REV. 2/13/24 INSTAXDSPX-A2B2
THINGS TO KNOW ABOUT THE AXDSP
A2B Connector
Important: Updating your interface with the Axxess Updater
is critical to the interface functioning properly.
Visit
axxessinterfaces.com
Select from the top menu bar. Updater Software
12 Pin Molex 16 Pin Molex
PC Axxess Updater
Download Axxess Updater
Micro-B Data Transfer Cable
Not included
