MetraOnline.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 9/6/23 INSTAX-LOC
AX-LOC
INSTALLATION INSTRUCTIONS
TABLE OF CONTENTS
Things to Know1 .......................................................
Connections
Adding a Subwoofer and Amplifier to Your
Factory system-Keeping Factory Speakers2 ....
Adding a 4 Channel Amplifier-Entire System
Not Using Radio’s Output3 .................................
Specifications4 .........................................................
LOC T-Harnesses have vehicle specific applications.
Please visit for the latest and up to date application information.AxxessInterfaces.com
TOOLS RECOMMENDED
• Digital Multi-meter
• Test Tones
Things to Know
• LOC T-harnesses are installed at the radio and designed for non-amplified vehicles. You can find dash
disassembly instructions from the on Vehicle Fit GuideAxxessInterfaces.com
• It is recommended that a polarity tester and tone generator be used before connecting your
aftermarket equipment.
• If your vehicle doesn’t have an accessory circuit your will not have an accessory () LOC T-HarnessRed
wire in the harness. Refer to the instructions for remote turn on options. Some vehicles AX-LOC
require the addition of load resistors, there are multiple options available. We recommend AX-LR20,
AX-LR39, and AX-LR60.
• Proper termination of loose wires is required.
