Seite 1/17
4 CHANNEL CLASS D
CAR AMPLIFIER
SMART DSP
Installation & Operation Manual / Einbau- & Bedienungsanleitung
A594DSP
– 2 –
Thank you for purchasing this innovative AXTON amplifier!
To maximize the performance of this amplifier and your complete car audio system installation,
we recommend you acquaint yourself thoroughly with all technical features and controlling op-
tions of this AXTON amplifier. Please read this manual carefully, before attempting the installation.
If, after reading this manual, you still have questions regarding functions or the installation of the
amplifier, we recommend you consult your dealer.
– 4 –
TECHNICAL SPECIFICATIONS A594DSP
DSP
DSP type: .................................... AKM7735 Dual DSP
ADC: ............................................ 2x 24-bit
DAC: ............................................ 2x 32-bit
DSP MHz: 2x 150 MHz ....................................
Audio sampling frequency:............. 192 kHz
BLUETOOTH
Bluetooth power class: .................. 2
Bluetooth power: 1 mW / 0 dBm ..........................
Bluetooth range: ........................... 10 m
Bluetooth Frequency: .................... 2.4 – 2.48 GHz
AMPLIFIER
Music Power Output 4/2 ohms: 76 W x 4 .....
RMS Power Output 4/2 ohms: ........ 50 W x 4
Frequency response: .................... 20Hz ~ 48 KHz
High-Level Sensitivity: ................... 4.2 Vrms
High-Level Impedance: ................. 39 Ohms
RCA max voltage: ......................... 5 Vrms
Supply voltage range: ................... 7.5 V – 16.5 V
Signal to noise ratio digital input: > 112 dB ...
Signal to noise ratio analogue input: > 106dB
THD: ........................................... 1 KHz < 0.02%
Damping factor: ........................... >= 200
Standby current: ........................... 0.23 A
Maximum operating current: .......... 20 A
Maximum Remote output power: .... 0.3 A
Dimensions (WxHxD): 218 x 40 x 114 mm ...................
MAIN FEATURES
·4-channel Smart Digital Amplifier with iOS or Android App controlled audio DSP functions
·6-channel DSP-controlled preout (5 Volt) including REM out to control additional amplifiers
·Optical and coaxial Input to connect the High-Res Audio interface ABT50 or another Axton DSP
·Optical Output to link the audio signal to another Axton DSP amplifier
·Bluetooth Audio Streaming with automatic source switching
·Plug’N’Play quick installation system by optional vehicle brand and model specific ISO
wire harness
·Auto-Turn-On function on high-level input
FUNCTIONALITY & ADJUSTABILITY
·Freely configurable active crossover: High-/Low-/Band-/Bypass with 6/12/18/24dB/Oct.
slope for each channel (Butterworth, Bessel or Linkwitz-Riley)
·Freely configurable 31-band parametric Equalizer for each channel
·Freely configurable 9-band parametric Input-Equalizer for each source
·Gain, Phase switch and Mute function for each channel
·Time Alignment for each channel (0 – 550 cm / 0 – 15.8 ms)
·Can save 5 memories in the amp and unlimited sound settings on the smartphone
·Dynamic Bass setting for powerful performance without subwoofer
·Noise Gate function to reduce car stereo background noise
