Installation Instructions for AX-TOYRSAV

© COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION

© COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION

REV. 2/3/16

REV. 2/3/16

Installation Instructions for AX-TOYRSAV

axxessinterfaces.com • metraonline.com

axxessinterfaces.com • metraonline.com

Axxess Integrate

Axxess Integrate

INTRODUCTION

The AX-TOYRSAV is designed to provide an audio/video input

to the OEM overhead video screen from the aftermarket radio

.

AX-TOYRSAV

Toyota RSE Retention Harness

2007-2010

APPLICATIONS

INTERFACE COMPONENTS

• AX-TOYRSAV harness

TOOLS REQUIRED

• Cutting Tool • Tape • Crimping Tool

• Connectors (i.e. butt-connectors, bell caps, etc.)

CONNECTIONS TO BE MADE

From the AX-TOYRSAV harness to the aftermarket radio:

• Connect the RCA jack to the right A/V-OUT jack.Red

• Connect the RCA jack to the left A/V-OUT jack.White

• Connect the Yellow RCA jack to the video A/V-OUT jack.

INSTALLING THE AX-TOYRSAV

• Connect the AX-TOYRSAV harness to the factory harness

located in the radio cavity.

TOYOTA (NAV MODELS ONLY)

4-Runner 2008-2009

Highlander 2008-2010

Sequoia 2008-2009

Sienna 2008-2010

Tundra 2007-2009

CAUTION!

All accessories, switches, climate controls panels, and especially air bag

indicator lights must be connected before cycling the ignition. Also, do not remove

the factory radio with the key in the on position, or while the vehicle is running.
