AXAC-CH3

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 5/14/25 INSTAXAC-CH3

ATTENTION: With the key out of the

ignition, disconnect the negative battery

terminal before installing this product.

Ensure that all installation connections,

especially the air bag indicator lights, are

plugged in before reconnecting the battery

or cycling the ignition to test this product.

NOTE: Refer also to the instructions

included with the aftermarket accessory

before installing this device.

TOOLS REQUIRED

INTERFACE COMPONENTS

REQUIRED ITEMS

TABLE OF CONTENTS

Introduction ...........................................................2

Interface Features ..................................................2

Configuration .....................................................2-4

Connections ............................................................5

Installation .............................................................6

Programming .........................................................7

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape • Wire cutter • Zip-ties

• AXAC-CH3 interface

• AXAC-CH3 interface harness

• AXAC-CH3 vehicle harness (qty. 2)

• 22-pin T-harness

• 22-pin T-harness (cam harness)

Update Cable: AXUSB-MCBL (sold separately)

Axxess Updater Program

*

With 8.4-inch U-Connect RB5 or RE2 radio

Camera Data Interface w/Pre-Wired Harness

Fits Select Chrysler/Dodge Models 2011-2018*

APPLICATIONS

Chrysler

300 ................................2011-2014

Dodge

Charger .........................2011-2014

Journey .........................2011-2018

Note: Only compatible with NTSC cameras.

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications

INTERFACE FEATURES

(see next page)
