AXAC-CH6

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 7/2/25 INSTAXAC-CH6

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator lights,

are plugged in before reconnecting the battery or

cycling the ignition to test this product.

NOTE:

Refer also to the instructions included with

the aftermarket accessory before installing this device.

INTERFACE FEATURES

TOOLS REQUIRED

INTERFACE COMPONENTS

REQUIRED ITEMS

TABLE OF CONTENTS

Introduction ...........................................................2

Configuration .....................................................2-4

Connections ............................................................5

Installation .............................................................6

Programming .........................................................6

Rebooting the U-Connect Radio ..........................7

• Add multiple CAN-activated cameras with 4 camera inputs

• Includes AXAC camera interface and vehicle-specific harness

• Programmable 12-volt 5-amp switched output (configured through

the Axxess Updater program)

• Reverse signal trigger generated via CAN bus communication of the

vehicle

• T

urn signal trigger generated via CAN bus communication of the vehicle

• 4 programmable camera control wires (configured through the

Axxess Updater program)

• Can also be manually controlled and used with an aftermarket radio

• VSS (Vehicle Speed Sense) input and output

• Retains factory backup camera

• Micro “B” USB updatable

• Crimping tool and connectors, or solder gun,

solder, & heat shrink • Tape • Wire cutter • Zip

ties

• AXAC-CH6 interface

• AXAC-CH6 interface harness

• AXAC-CH6 vehicle harness

Update Cable: AXUSB-MCBL (sold separately)

Axxess Updater Program

Camera Data Interface w/Pre-Wired

Harness

Fits Select Jeep/Ram Models 2014-2020

APPLICATIONS

Jeep

Compass (with 5" U-Connect radio) .........................2017.5-2020

Renegade .......................................................................2015-2018

Ram

Promaster (with 5" U-Connect radio) ......................... 2014-2019

Promaster City (with 5" U-Connect radio) .................. 2015-2017

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications
