AXDIS-CL2

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 5/15/25 INSTAXDIS-CL2

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator lights, are

plugged in before reconnecting the battery or cycling

the ignition to test this product.

NOTE: Refer also to the instructions included with the

aftermarket accessory before installing this device.

INTERFACE FEATURES

INTERFACE COMPONENTS

TABLE OF CONTENTS

Applications ...........................................................2

Tools Required .......................................................2

Connections

Non-Amplified Models .......................................3

Amplified Models ................................................4

Installation .............................................................5

Programming .....................................................5-6

Adjusting the AXDIS-CL2 .......................................7

Extra features .....................................................7-8

Steering wheel control settings ......................9-12

LED feedback .......................................................9

Changing radio type .........................................10

Remapping ........................................................10

Dual assignment instructions .....................11-12

Troubleshooting....................................................12

Radio Replacement Data Interface with SWC

Fits Select GM Models2000-2014

APPLICATIONS

See inside front cover

•

Designed for non-amplified, or analog/digital amplified models

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (Retained Accessory Power)

• Provides NAV outputs (parking brake, reverse, speed sense)

• Retains audio controls on the steering wheel

•

Retains OnStar

®

, OEM Bluetooth

®

connectivity, and satellite

radio if equipped

• Adjustable volume for OnStar

®

• Retains balance & fade (excludes digital amplified models)

• Retains chimes and factory AUX-IN jack

• Retains Rear Seat Entertainment (RSE must be activated by the

factory radio)

• Micro “B” USB updatable

• AXDIS-CL2 interface • AXDIS-CL2 harness

• 16-pin harness with stripped leads • 4-pin to 4-pin resistor pad

• Female 3.5mm connector with stripped leads

Product Infowww.MetraOnline.com

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications.

For Dash Disassembly

Instructions, refer to

metraonline.com .Enter the

year, make, and model of

the vehicle in the Vehicle Fit

Guide for Radio Install kits.
