AXDIS-GMLN30

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/1/24 INSTAXDIS-GMLN30

Chevrolet

Blazer (IOT, IOU)* ...........2019-2023

Camaro (IOS, IOT)* .........2019-2023

Cheyenne (IOS, IOT)* ......2019-2021

Colorado (IOS, IOT) .........2019-2022

Equinox (IOS, IOT)* ........2019-2023

Malibu (IOU, IOS)* ..........2019-2022

Silverado (IOS, IOT)* .......2019-2021

Volt ............................................2019

GMC

Acadia (IOU)* ................2020-2022

Canyon (IOS, IOT) ...........2019-2022

Sierra 1500 (IOS, IOT)* ....2019-2021

Terrain (IOS, IOT, IOU)

* ...2019-2022

INTERFACE FEATURES

INTERFACE COMPONENTS

TABLE OF CONTENTS

Connections ........................................................2-3

3.5mm Jack Steering Wheel Control Retention

...3

Installing the AXDIS-GMLN30 ................................3

Programming the AXDIS-GMLN30 ........................4

Steering Wheel Control Settings (SWC)...........5-8

LED Feedback .......................................................5

Changing Radio Type ..........................................5

Remapping the SWC Buttons .................................6

Dual Assignment Instructions.........................7-8

Troubleshooting.....................................................8

GM Data Interface with SWC 2019-2023

•

Non-amplified models only

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, speed sense)

• Retains audio controls on the steering wheel

• Retains balance and fade

• Micro-B USB updatable

• AXDIS-GMLN30 interface • AXDIS-GMLN30 harness

• 16-pin harness with stripped leads

• Female 3.5mm connector with stripped leads

TOOLS REQUIRED

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell

caps, etc.) • Small flat-blade screwdriver

APPLICATIONS

*For extension,

use AXEXH-GM30

Product Info

Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
