AXDIS-TY3

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/22/24 INSTAXDIS-TY3

INTERFACE FEATURES

TOOLS REQUIRED

Fits Toyota Interface with SWC 2018-2023

• Designed for both amplified and non-amplified models

• Provides accessory power (12-volt 10-amp)

• Provides NAV outputs (parking brake, reverse, speed sense)

• Retains the factory AUX-IN jack

• Retains the factory backup camera

• Includes an AXCSD-6V 12-to-6V step-down for the factory camera

• Retains audio controls on the steering wheel

• Retains balance on amplified models

(non-amplifed models retain balance and fade)

• Micro-B USB updatable

INTERFACE COMPONENTS

• AXDIS-TY3 interface • AXDIS-TY3 harness (LD-TYAMP3-SWC)

• Female 3.5mm connector with stripped leads

• AXCSD-6V

TABLE OF CONTENTS

Applications ...........................................................2

Connections:

LD-TYAMP3-SWC ....................................................3

3.5mm Jack Steering Wheel Control Retention

...4

Installing the AXDIS-TY3........................................4

Programming the AXDIS-TY3 ...............................5

Audio Level Adjustment .......................................5

Steering Wheel Control Settings ......................6-9

LED Feedback .......................................................6

Changing Radio Type ..........................................7

Remapping the SWC Buttons .............................8

Dual Assignment Instructions

.............................9

Troubleshooting...................................................10

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications.

•

Crimping tool and connectors, or solder gun, solder, and heat shrink

• Small flat-blade screwdriver • Tape

• Wire cutter • Zip ties

ATTENTION: With the key out of the ignition,

disconnect

the negative battery terminal before installing

this product. Ensure that all installation connections,

especially the air bag indicator lights, are plugged in

before reconnecting the

battery or cycling the ignition to

test this product.

NOTE: Refer also to the instructions included with the

aftermarket accessory before installing this device.

APPLICATIONS (See Page 2)

MetraOnline.com may be used

to assist with dash assembly

instructions. Simply enter your

Year, Make, Model vehicle into

the vehicle fit guide and look

for the Dash Kit Installation

Instructions.
