AXVI-1784

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

1-800-221-0932metraonline.com

REV. 1/21/20

AXVI-1784

AXVI-1784AXVI-1784

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

1-800-221-0932metraonline.com

REV. 1/21/20

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

1-800-221-0932metraonline.com

REV. 1/21/20© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

1-800-221-0932metraonline.com

REV. 1/21/20

AXVI-1784

Dodge/Mercedes/Freightliner accessory and NAV output

CAN harness 2007-2013

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

APPLICATIONS

WIRING UP THE AXVI-1784

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

AXVI-1784

DODGE

Sprinter 2007

Sprinter

(sound 5 radio) 2008-2009

MERCEDES

Sprinter

(sound 5 radio) 2010-2013

FREIGHTLINER

Sprinter 2007

Sprinter(sound 5 radio) 2008-2013

Dodge/Mercedes/Freightliner accessory and NAV output

CAN harness 2007-2013

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

APPLICATIONS

WIRING UP THE AXVI-1784

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

DODGE

Sprinter 2007

Sprinter

(sound 5 radio) 2008-2009

MERCEDES

Sprinter

(sound 5 radio) 2010-2013

FREIGHTLINER

Sprinter 2007

Sprinter(sound 5 radio) 2008-2013

AXVI-1784

Dodge/Mercedes/Freightliner accessory and NAV output

CAN harness 2007-2013

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

APPLICATIONS

WIRING UP THE AXVI-1784

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

AXVI-1784

DODGE

Sprinter 2007

Sprinter

(sound 5 radio) 2008-2009

MERCEDES

Sprinter

(sound 5 radio) 2010-2013

FREIGHTLINER

Sprinter 2007

Sprinter(sound 5 radio) 2008-2013

Dodge/Mercedes/Freightliner accessory and NAV output

CAN harness 2007-2013

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

APPLICATIONS

WIRING UP THE AXVI-1784

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

DODGE

Sprinter 2007

Sprinter

(sound 5 radio) 2008-2009

MERCEDES

Sprinter

(sound 5 radio) 2010-2013

FREIGHTLINER

Sprinter 2007

Sprinter(sound 5 radio) 2008-2013
