AXVI-9003

Volkswagen accessory and NAV output CAN harness 2002-up

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in both amplified and non-amplified systems*

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

*excluding Fender audio systems

APPLICATIONS

WIRING UP THE AXVI-9003

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the orange wire.

• The Blue wire is not used in this application.

AXVI-9003

VOLKSWAGEN

Beetle 2012-up

CC 2009-up

EOS 2007-up

Golf (with double DIN radio) 2002

Golf 2003-2006

Golf/Golf R 2010-up

GTI 2002-up

Jetta (with double DIN radio) 2002

Jetta 2003-up

Jetta GLI 2008-up

Jetta Sportwagen 2010-up

Passat 2002-up

R32 2007-2008

Rabbit 2007-2009

Tiguan 2009-up

Volkswagen accessory and NAV output CAN harness 2002-up

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in both amplified and non-amplified systems*

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

*excluding Fender audio systems

APPLICATIONS

WIRING UP THE AXVI-9003

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the orange wire.

• The Blue wire is not used in this application.
