METRA. The World’s best kits.™metraonline.com1-800-221-0932

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Installation Instructions for AXVRI

REV. 2/3/2020 INSTAXVRI

AXVRI

Voltage Retention Interface

CONNECTIONS TO BE MADE

From the 8-pin harness to the vehicle-side harness:

• Connect the (3) Black wires to the ground wire.

• Connect the Yellow fused wire to the battery wire.

• Connect the Red fused wire to the accessory wire.

From the 6-pin harness to the aftermarket radio:

• Connect the (2) Black/White wires together, then connect them to

the ground wire.

• Connect the (2) Yellow/White wires together, then connect them to the

battery wire.

• Connect the (2) Red/White wires together, then connect them to the

accessory wire.

Note: Each individual line is rated at 5-amps per line (10-amps

combined total). If each line is going to be used for separate sources--

or the current will surpass 10-amps--please use a relay, Metra part

number E-123 to increase current.

Caution: Metra recommends disconnecting the negative battery terminal before beginning

any installation. All accessories, switches, and especially air bag indicator lights must be

plugged in before reconnecting the battery or cycling the ignition.

*Note: Refer also to the instructions included with the aftermarket radio.

INTERFACE COMPONENTS

• AXVRI Interface • 8-pin harness with stripped leads and fuses

• 6-pin harness with stripped leads

TOOLS REQUIRED

• Cutting tool • Tape • Crimping tool

• Connectors (i.e. butt-connectors, bell caps, etc.)

FEATURES

• Provides 12-volt output when voltage drops below 7-volts

• Designed for vehicles that drop voltage while stopped

• Fuses included for safety

• Provides accessory power (12-volt 10-amp)
