B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

FEATURES

BT8009

FLAT SCREEN MOUNTING PLATE

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Mount

Crosshead

screwdriver

Drill

Pencil

Stud finder

(optional)

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Typical Installations ............................................................................................................................6

Flat Screen Interfaces.......................................................................................................................10

Product Dimensions..........................................................................................................................11

B-Tech Contact Details.....................................................................................................................12

PLEASE KEEP THIS FOR FUTURE REFERENCE

13mm (1/2") spanner

or socket

10mm (7/16") masonry bit

or 6mm (1/4") wood bit

●Designed for flat screens up to 60” (153cm) / 70kg (154lbs)

●Suitable for concrete / brick or stud walls up to 12”

●Mounts screen only 22mm from wall when BT7507 interface is use

d

●Security screws included

●Simple hook-on installation with all mounting hardware included

●Compatible with BT8016, BT8017 and BT8026, BT8027 for

back to back screen mounting

●Fixes to non B-Tech trolley / floor stands (with pole centres

62.5mm – 157.5mm or 204mm – 299mm) using accessory collars

●Must be used with flat screen interface kit (BT7507 / BT8600 / 

BT8500/BT8501)

Actual screen size & weight limit

dependant on the interface to

which BT8009 is attached
