BDI Format 6307 Bedienungsanleitung
Seiten 2 Kleiderschrank
Lies die Bedienungsanleitung für BDI Format 6307 kostenlos online oder lade das PDF herunter. Diese Anleitung wurde 63 Mal aufgerufen. Frage zu diesem Modell? Stelle eine Frage
1
C - 5/32" x 12mm
Phillips Screw
x 20
E - Center Caster x 1
I - Letter File Bar x 2
D - Brake Caster x 4
B - Cabinet x 1
F - M4 x 37mm
Phillips Screw
x 2
G - M4 x 25mm
Phillips Screw
x 2
H - Pull x 2
FORMAT
6307
Format is engineered for easy assembly. Carefully follow this
procedure to prevent any damage.
Do not use power tools for assembly of this product.
Placement and Maintenance
Format™ Office furniture is designed for indoor use on level floors.
Clean steel parts and wood veneer with a moist cloth.
Step 1
Unpack and Identify
Unpack and identify the components at left. Note that some
components are shipped inside the cabinet. The assembly
workspace should be a non-marring surface such as carpet. For
missing hardware pieces, please contact BDI Customer Service
at [email protected]. For all other concerns, please
contact your BDI Retailer.
Step 2
Install Casters
Carefully position Cabinet (B) on its back side so that bottom side
is accessible, then attach a Caster at each of the five (5) exposed
installation plates using 5/32" x 12mm Phillips Screw (C) and a
Phillips Screwdriver.
Component List
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and
international patents, trade dress, and/or copyright laws.
BDI and Format are trademarks of Becker Designed, Inc.
All Rights reserved. ©2012, BDI
Made in Taiwan. 6307REV022312v1
A - Phillips Screwdriver
x 1 (not provided)
C x 4
E x 1
C x 16
D x 4
ASSEMBLY INSTRUCTIONS
BDIUSA.COM [email protected]
Produktspezifikationen
| Marke: | BDI |
| Kategorie: | Kleiderschrank |
| Modell: | Format 6307 |
| Breite: | 390 mm |
| Tiefe: | 610 mm |
| Gewicht: | 29937 g |
| Höhe: | 640 mm |
| Lenkrollen: | Nein |
| Verpackungsbreite: | 482.6 mm |
| Verpackungstiefe: | 711 mm |
| Verpackungshöhe: | 640 mm |
| Paketgewicht: | 34019 g |
| Rahmenfarbe: | Schwarz |
| Anzahl der Schubladen: | 2 Schublade(n) |
| Designer: | Matthew Weatherly |
