H61MHV/H61MGV/H61MLC2 Setup Manual

FCC Information and Copyright

This equipment has been tested and found to comply with the limits of a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. There is no guarantee

that interference will not occur in a particular installation.

The vendor makes no representations or warranties with respect to the

contents here and specially disclaims any implied warranties of merchantability

or fitness for any purpose. Further the vendor reserves the right to revise this

publication and to make changes to the contents here without obligation to

notify any party beforehand.

Duplication of this publication, in part or in whole, is not allowed without first

obtaining the vendor’s approval in writing.

The content of this user’s manual is subject to be changed without notice and

we will not be responsible for any mistakes found in this user’s manual. All the

brand and product names are trademarks of their respective companies.

Dichiarazione di conformità

sintetica

Ai sensi dell’art. 2 comma 3 del D.M.

275 del 30/10/2002

Si dichiara che questo prodotto è

conforme alle normative vigenti e

soddisfa i requisiti essenziali richiesti

dalle direttive

2004/108/CE, 2006/95/CE e

1999/05/CE

quando ad esso applicabili

Short Declaration of conf ormity

We declare this product is complying

with the laws in force and meeting all

the essential requirements as specified

by the directives

2004/108/CE, 2006/95/CE and

1999/05/CE

whenever these laws may be applied

Table of Contents

Chapter 1: Introduction ........................................ 1

1.1 Before You Start......................................................................................... 1

1.2 Package Checklist ..................................................................................... 1

1.3 Motherboard Features .............................................................................. 2

1.4 Rear Panel Connectors.............................................................................. 3

1.5 Motherboard Layout ................................................................................. 4

Chapter 2: Hardware Installation .......................... 5

2.1 Installing Central Processing Unit (CPU) ............................................... 5

2.2 FAN Headers .............................................................................................. 7

2.3 Installing System Memory ........................................................................ 8

2.4 Connectors and Slots................................................................................ 10

Chapter 3: Headers & Jumpers Setup .................. 13

3.1 How to Setup Jumpers............................................................................. 13

3.2 Detail Settings .......................................................................................... 13

Chapter 4: Useful Help ........................................ 16

4.1 Driver Installation Note .......................................................................... 16

4.2 Software .................................................................................................... 17

4.3 Extra Information .................................................................................... 21

4.4 AMI BIOS Beep Code ............................................................................... 22

4.5 Troubleshooting ....................................................................................... 23

Appendix: SPEC In Other Languages ................... 24

German .................................................................................................................. 24

French .................................................................................................................... 26

Italian..................................................................................................................... 28

Spanish ................................................................................................................... 30

Portuguese ............................................................................................................ 32

Polish ...................................................................................................................... 34

Russian ................................................................................................................... 36

Arabic..................................................................................................................... 38

Japanese ................................................................................................................ 40

Produktspezifikationen

Marke:	Biostar
Kategorie:	Hauptplatine
Modell:	H61MHV 7.x
Prozessorhersteller:	Intel
Breite:	226 mm
Tiefe:	170 mm
Mitgelieferte Kabel:	SATA
Energiequelle:	ATX
Kopfhörerausgänge:	1
Anzahl USB 2.0 Anschlüsse:	4
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Anzahl HDMI-Anschlüsse:	1
Audio Kanäle:	5.1 Kanäle
HDCP:	Ja
Mikrofon-Eingang:	Ja
Schnellinstallationsanleitung:	Ja
Prozessorsockel:	LGA 1155 (Socket H2)
Anzahl VGA (D-Sub) Anschlüsse:	1
Kompatible Prozessoren:	Intel Celeron, Intel Pentium
Motherboardformfaktor:	micro ATX
Motherboard Chipsatz Familie:	Intel
Motherboard Chipsatz:	Intel® H61
Audio-Chip:	Realtek ALC662
Komponente für:	PC
Unterstützte Arbeitsspeicher:	DDR3-SDRAM
Anzahl der Speichersteckplätze:	2
Arbeitsspeicher Typ:	DIMM
Speicherkanäle:	Zweikanalig
Unterstützte Arbeitsspeichergeschwindigkeit:	1066,1333,1600 MHz
RAM-Speicher maximal:	16 GB
Unterstützte Speicherlaufwerk-Schnittstellen:	SATA II
PCI-Express x16 (Gen 3.x)-Anschlüsse:	1
PCI-Express x1 (Gen 2.x)-Anschlüsse:	1
Treiber enthalten:	Ja
Anzahl PS/2 Anschlüsse:	2
Anzahl USB 2.0 Schnittstellen:	2
CPU Ventilatorstecker:	Ja
Front Panel Audiostecker:	Ja
Serielle Port-Headers:	1
Ethernet Schnittstellen Typ:	Gigabit Ethernet
LAN-Controller:	Realtek RTL8111F
SATA II Anschlüsse:	4
SATA Anschlüsse:	4
Prozessor Verlustleistung (max):	95 W
Ethernet/LAN:	Ja
