Seite 1/8

24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM

EMERALD 4K

RACKMOUNT

TRAY

EMD4000-RMK1

INSTALLATION GUIDE

TABLE OF CONTENTS

NEE D HELP ?

LE AV E TH E TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1.877.877.2269

1.877.877.2269 BLACKBOX.COM

1. OVERVIEW ...................................................................................................................................................................................... 3

1.1 Introduction ...............................................................................................................................................................................................3

1.2 Safety.........................................................................................................................................................................................................3

1.3 What’s Included ........................................................................................................................................................................................3

1.4 Rackmount Tray Illustrated 3 .....................................................................................................................................................................

2. INSTALLATION INSTRUCTIONS .................................................................................................................................................. 4

2.1 Installing the Rackmount Tray 4 .................................................................................................................................................................

2.2 Installing the Transmitter or Receiver 6 ....................................................................................................................................................

APPENDIX: DISCLAIMER/TRADEMARKS ....................................................................................................................................... 7

A.1 Disclaimer .................................................................................................................................................................................................7

A.2 Trademarks Used in this Manual 7 ............................................................................................................................................................

1.877.877.2269 BLACKBOX.COM

NEE D H ELP?

LE AVE THE TE CH TO U S

LIVE 24/7

TECHNICAL

SUPPORT

1.877.877.2269

CHAPTER 1: OVERVIEW

1.1 INTRODUCTION

Use the Emerald 4K Rackmount Tray (EMD4000-RMK1) to mount up to (2) Emerald 4K Transmitter and/or Receiver (EMD4000-T/R) units

in a 2-/4-post 19" rack or cabinet.

1.2 SAFETY

WARNING!

Rack loading — Overloading or uneven loading of racks may result in shelf or rack failure, possibly damaging the equipment and

causing personal injury. Stabilize racks in a permanent location before loading begins. Do not exceed your rack’s load rating.

1.3 WHAT’S INCLUDE D

The EMD4000-RMK1 contains the following:

Rack Tray (including one blank panel)

Hardware kit – (2) locking brackets, (4) each screw & cage nuts, (2) thumbscrews, (8) M3 x 6mm countersunk screws

Insert Card – How to download your documentation

1.4 R ACKMOUNT TRAY ILLUSTRATED

Figure 1-1 shows the inside of the rackmount tray.

Power adapter

Cable routing

Stop guides

FIGURE 1-1. INSIDE OF THE RACKMOUNT TRAY

Produktspezifikationen

Marke:	Black Box
Kategorie:	Nicht kategorisiert
Modell:	EMD4000-RMK1
Breite:	431 mm
Tiefe:	355 mm
Gewicht:	770 g
Produktfarbe:	Schwarz
Höhe:	43 mm
Material:	Metall
Zertifizierung:	TAA
Nachhaltigkeitskonformität:	Ja
Kompatibilität:	EMD4000T/R
Schrauben enthalten:	Ja
