Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

This 15-amp, vertically mounted distribution unit is

60 inches long, features a current meter, and has

24 outlets.

15-Amp Metered Vertical PDU, 24-Outlet (5-15R)

PDUMV24-S15-120V

Overview

The metered PDU LCD display shows the current power draw in amps.

The metered PDU only has one function button, MUTE, located next to

the display. The metered PDU’s alarm sounds when the current draw

reaches 80% of capacity. The alarm can be turned off by pressing the

MUTE button. When the current draw exceeds 90% of the maximum

current rating, the alarm cannot be muted, and the PDU alarms until the

current draw is reduced.

Environmental: Operating Temperature: 32 to 104° F (0 to 40° C);

Storage Temperature: 32 to 149° F (0 to 65° C);

Operating and Storage Humidity: 0 to 90%, noncondensing relative

UL Listed: Yes (UL 60950-1)

RoHS: Yes

Specifications

Circuit Breaker: 15 A

Cord Connector: 5-15P

Cord Length: 6 ft. (1.8 m)

Cord Type: 14/3C

Current Alarm: Yes

Current Rating: 12 amps (UL

60950-1)

Input Voltage: 120 VAC

Metered: Yes, 3-digit LCD

Mounting: Vertical

Number of Outlets: 24

Outlet Location: Front

Outlet Max. Current: 12 A

Outlet Type: 5-15R

Indicator: Power LED

FREE, live, 24/7 Tech Support is just 30 seconds away.

724-746-5500 | blackbox.com

Safety Instructions

1. The PDU is designed for indoor use only in a controlled environment away from excess moisture, temperature extremes,

conductive contaminants, dust, or direct sunlight.

2. Do not connect the PDU to an ungrounded outlet or extension cords or adapters that eliminate the connection to ground.

3. The power requirement for each piece of equipment connected to the PDU must not exceed the individual outlet’s load rating.

4. The total power requirements for equipment connected to the PDU must not exceed the maximum load rating.

5. Do not drill into or attempt to open any part of the PDU. There are no user-serviceable parts inside.

6. Do not attempt to modify the PDU, including input plugs and power cables.

7. To reduce the risk of fire, connect only to a branch circuit with overcurrent protection in accordance with the National Electric

Code, ANSI/NFPA 70(3KVA).

What’s included

• 24-outlet vertical PDU

• (2) mounting brackets

• (4) mounting screws

• Specification sheet

and the Double Diamond logo are registered trademarks of BB Technologies, Inc. UL is a registered

trademark of Underwriters Laboratories. Any third-party trademarks appearing in this publication are acknowledged to be the property of their respective owners.

PDUMV24-S15-120V, rev. 1
