User Manual
User Manual
Introduction 3 ..........................................................................................................
Features 3 .................................................................................................................
Specications ........................................................................................................3
Package Contents 3 .................................................................................................
Front 4 .......................................................................................................................
Back 4 .......................................................................................................................
Connection Diagrams 5 ...........................................................................................
Signal Flow/Hardware Block Diagram 5 ..................................................................
Repair 6 .....................................................................................................................
Warranty 6 ................................................................................................................
Disclaimer 6 ..............................................................................................................
Copyright 7 ...............................................................................................................
The B173 is largely based on the classic design of a Neve 1073. We originally set out
to create a direct clone, but ultimately decided to pursue our own unique design that
combined both modern and vintage characteristics in a portable, compact enclosure.
The B173 is a “Class A,” fully discrete preamp with a single-ended microphone amplier
and a balanced output amplier. It is a single channel preamp with input and output
transformers, stepped gain, an output attenuator, phantom power, and switchable phase.
It features up to 80dB of gain, is housed in a 1U, 1/2 rack chassis, and has a high-impedance
DI input that will work with anything from guitars to keyboards.
Our aim was to combine the creamy fullness of a Neve 1073 with the polished clarity found
in many expensive, modern preamps. The result is a well-balanced, smooth-sounding
preamp with low noise and plenty of gain.
INTRODUCTION
FEATURES
SPECIFICATIONS
Gain: 12dB to 80dB
THD+N:
• @12dB Gain = .07%
• @ 62dB Gain = .14%
Power: 24VAC, 500mA External Supply
Weight: 3.2 lbs
Dimensions: 9.5” x 6.5” x 1.75”
Shipping weight: 5.5lbs
Shipping dimensions: 13” x 11” x 5”
• Cinemage Input Transformer
• Edcor Output Transformer
• 80dB Gain
• D.I. Input (active, unbalanced)
• Phantom Power
• Phase Switch
• Output Attenuator
• XLR Microphone Input
• TRS Line Output (balanced)
• B173
• Power Supply (wall wart)
• ½ Rack Connector Plate
PACKAGE CONTENTS
