Seite 1/16

Page 2

TABLE OF CONTENTS

Motif Sketch™ 1

1. Getting Started 3

What’s In The Box? 3

Getting It Out Of The Box 3

Optional Accessories 3

Powering Up! 3

Getting A Hold Of Us 3

Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4

2. Meet The Motif Sketch™ 5

Features 5

DMX Quick Reference 5

The

Motif Sketch™ Pin-up Picture 6

3. Setup 7

Fuse Replacement 7

Connecting A Bunch Of Motif Sketch™’s 7

Data/DMX Cables 7

Cable Connectors 8

3-Pin??? 5-Pin??? Huh? 8

Take It To The Next Level: Setting up DMX Control 8

Fixture Linking (Master/Slave Mode) 9

Mounting/Rigging 9

4. Operating Adjustments 10

The Remote Control 10

Setting the DMX Address 10

Static Colors 10

DMX Mode 10

Blackout 11

Built-in Programs 11

Auto Mode 11

Manual Color Adjustments 11

Restore Factory Settings 11

5. Appendix 12

A Quick DMX Lesson 12

Troubleshooting 12

Keeping Your Motif Sketch™ As Good As New 13

Returns (Gasp!) 13

Shipping Issues 13

Tech Specs 14

Page 3

1. GETTING STARTED

What’s In The Box?

• 1 x Motif Sketch™ LED Fixture

• 1 x DMX Signal Cable

• 1 x IP Rated AC Power Cord with Cable Cap

• 1 x IR Remote Control

• This Lovely User Manual

Getting It Out Of The Box

Congratulations on purchasing one of the brightest, cutest little outdoor rated xtures

anywhere! Now that you’ve got your Motif Sketch™ (or hopefully, ), you should Sketch’s!

carefully unpack the box and check the contents to ensure that all parts are present and

in good condition. If anything looks as if it has been damaged in transit, notify the shipper

immediately and keep the packing material for inspection. Again, please save the carton

and all packing materials. If a xture must be returned to the factory, it is important that

the xture be returned in the original factory box and packing.

Powering Up!

All xtures must be powered directly o a switched circuit and cannot be run o a

rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer

channel is used solely for a 0% to 100% switch.

AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the

xture you receive is suitable for your local power supply. See the label on the xture or

refer to the xture’s specications chart for more information. A xture’s listed current

rating is its average current draw under normal conditions. Check the xture or device

carefully to make sure that if a voltage selection switch exists that it is set to the correct

line voltage you will use.

Warning! Verify that the voltage select switch on your unit matches the line

voltage applied. Damage to your xture may result if the line voltage applied does

not match the voltage indicated on the voltage selector switch. All xtures must

be connected to circuits with a suitable Ground (Earthing).

Getting A Hold Of Us

If something happens goes wrong, please visit www.blizzardlighting.com/

support and open a support ticket. We’ll be happy to help, honest.

Disclaimer: The information and specications contained in this document are subject

to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any

errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the

right to update the existing document or to create a new document to correct any errors

or omissions at any time. You can download the latest version of this document from www.

blizzardlighting.com.

Author: Date: Last Edited: Date:

J. Thomas 12/17/2012 J. Thomas 10/11/2016

Produktspezifikationen

Marke:	Blizzard Lighting
Kategorie:	Lichteffektmaschine
Modell:	Motif Sketch
Breite:	75 mm
Tiefe:	160 mm
Gewicht:	1300 g
Produkttyp:	Disco-Par-Licht
Produktfarbe:	Schwarz
Internationale Schutzart (IP-Code):	IP65
Höhe:	90 mm
Energiequelle:	AC
Fernbedienung enthalten:	Ja
Stromverbrauch (Standardbetrieb):	23 W
Lampentyp:	LED
Eingangsspannung:	100 - 260 V
Für die Nutzung im Innenbereich geeignet:	Ja
Anzahl Lampe(n):	7 Lampen
Beleuchtungsarten:	Master/slave, Stand-alone
Beleuchtungssteuerungsprotokolle:	DMX
Anzahl der DMX-Kanäle:	3 Kanäle
Fernbedienungsfunktion:	Ja
DMX-Eingang:	Ja
DMX-Ausgang:	Ja
Anzahl Pins:	3
Eingangsfrequenz:	50/60 Hz
Fernbedienungstyp:	IR
Lampenleistung:	3 W
Für die Nutzung im Außenbereich geeignet:	Ja
Gewährleistungsfrist:	2 Jahr(e)
