Blizzard Motif Metro Bedienungsanleitung
Blizzard
Effektmaschine
Motif Metro
Lies die bedienungsanleitung für Blizzard Motif Metro (16 Seiten) kostenlos online; sie gehört zur Kategorie Effektmaschine. Dieses Handbuch wurde von 37 Personen als hilfreich bewertet und erhielt im Schnitt 4.4 Sterne aus 19 Bewertungen. Hast du eine Frage zu Blizzard Motif Metro oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage
Seite 1/16
Blizzard Lighting, LLC
http://www.blizzardpro.com
Waukesha, WI USA
Copyright (c) 2021
SUITABLE FOR OUTDOOR USE
Page 2
Motif™ Metro User Manual Rev. A © 2020 Blizzard Lighting, LLC
TABLE OF CONTENTS
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of the Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions 4
2. Meet the Motif™ Metro 5
Main Features 5
DMX Quick Reference 5
Motif™ Metro Pin-Up Picture 6
The Rear Connections 6
3. Setup 7
Fuse Replacement 7
Connecting A Bunch of Motif™ Metro Fixtures 7
Data/DMX Cabling 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh?!? 8
Take It To The Next Level: Setting Up DMX Control 8
Fixture Linking (M/S Mode) 9
Mounting & Rigging 9
4. Operating Adjustments 10
The Control Panel 10
Control Panel Menu Structure 11
DMX Mode 12
Starting DMX Address 12
DMX Channel Mode 12
M/S Mode 12
Auto Mode 12
Manual Mode 12
Dimming Modes 13
DMX Values In-Depth 13
5. Appendix 14
Keeping Your Motif™ Metro As Good As New 14
Returns (Gasp!) 14
Shipping Issues 14
Tech Specs! 15
Dimensional Drawings 15
Page 3
Motif™ Metro User Manual Rev. A © 2020 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• 1 x Motif™ Metro
• 1 x IP Rated AC Power Cord
• 2 x Mounting Brackets
• This Lovely User Manual
Getting It Out Of the Box
Congratulations on purchasing the Motif™ Metro, the ultra-bright and durable
IP65-rated LED wash xture. Now that you’ve got your Motif™ Metro, you
should carefully unpack the box and check the contents to ensure that all parts
are present and in good condition. If anything looks as if it has been damaged
in transit, notify the shipper immediately and keep the packing material for
inspection. Again, please save the carton and all packing materials. If a xture
must be returned to the factory, it is important that the xture be returned in
the original factory box and packing.
Powering Up!
All xtures must be powered directly o a switched circuit and cannot be run
o a rheostat (variable resistor) or dimmer circuit, even if the rheostat
or dimmer channel is used solely for a 0% to 100% switch.
Warning! All xtures must be connected to circuits with a suitable
Ground (Earthing).
Getting A Hold Of Us
If something happens to go wrong, please visit www.blizzardpro.com/
support and open a support ticket. We’ll be happy to help, honest.
Disclaimer: The information and specications contained in this document are
subject to change without notice. Blizzard Lighting™ assumes no responsibility
or liability for any errors or omissions that may appear in this user manual.
Blizzard Lighting™ reserves the right to update the existing document or to
create a new document to correct any errors or omissions at any time. You can
download the latest version of this document from www.blizzardpro.com.
Author: Date: Last Edited: Date:
J. Thomas 8/12/2020 J. Thomas 3/8/2021
