DA11USB-V2
Dante
®
USB Audio Encoder / Decoder
Description
Our DA11USB-V2 has been designed to both encode 2ch USB audio
to a Dante® digital signal, and decode a Dante® digital signal to 2ch
USB audio. The DA11USB-V2 features both USB Type-B and USB-C
connections selectable via local dip-switch and is a plug & play
device that is powered using PoE (Power Over Ethernet) or via 5V
from the USB device. The DA11USB-V2 also supports AES67 RTP
audio transport.
Key Features
•
Encodes 2ch USB audio to Dante® digital signal
•Decodes a Dante® digital signal to USB audio
•Selectable USB audio between USB Type-B and USB-C
inputs
•Compliant with USB Audio Device Class Specication V2.0
•USB Audio Supports 44.1, 48, 88.2, 96, 176.4 & 192 KHz
sample rates @ 16, 24 & 32 Bit
•Dante® Audio Supports 44.1, 48, 88.2 & 96 KHz sample
rates @ 16, 24 & 32 Bit
•Congurable Dante® device latency (supports 2, 3, 4, 5 or
10ms congurable using Dante® Controller)
•Supports AES67 RTP audio transport
•Features Class 0 IEEE 802.3af PoE for powering of product
from any PoE switch
•Supports power via 5V USB for when network switch does
not support PoE
Specications
•
Audio Input Connectors: 1 x RJ45, female (100Mbps Dante
®
network), 1 x USB Type B female, 1 x USB Type C female
•Audio Output Connectors: 1 x RJ45, female (100Mbps
Dante
®
network), 1 x USB Type B female, 1 x USB Type C
female
•Casing Dimensions (W x H x D): 120mm x 26mm x 47mm
without feet
•Shipping Weight: 0.3kg
•Operating Temperature: 32°F to 104°F (0°C to 40°C)
•Storage Temperature : -4°F to 140°F (-20°C to 60°C)
•Power Supply: Class 3 IEEE 802.3af PoE or 5v USB
Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.
120mm
26mm
47mm
USB-B
USB-C
USB-B
RESET
USB-C
Regulatory Compliance
CAN ICES-003 (B)/NMB-003(B)
