Bosch PBH6B5B90A Bedienungsanleitung
Lies die bedienungsanleitung für Bosch PBH6B5B90A (12 Seiten) kostenlos online; sie gehört zur Kategorie Herd. Dieses Handbuch wurde von 4 Personen als hilfreich bewertet und erhielt im Schnitt 4.4 Sterne aus 2.5 Bewertungen. Hast du eine Frage zu Bosch PBH6B5B90A oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage
Seite 1/12
USER INSTRUCTIONS
INSTALLATION INSTRUCTIONS
MAINTENANCE INSTRUCTIONS
*
0.
This cooktop is for use with Natural Gas and
Universal LPG
Leave this instructions with the owner
PBH6B5B80A, PBH6B5B60A, PBH6B5B90A
en
2
Table of contents
[ en] I n st r uct i on manu al
(Important safety information . . . . . . . . . . . . . . . 2
For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What to do if you smell gas . . . . . . . . . . . . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
5Installation and connection. . . . . . . . . . . . . . . . . 3
Statutory requirements . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preparing to install . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation of cooktop into the kitchen bench . . . . . . . 4
Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Converting the cooktop from Nat. Gas to
Universal LPG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Changing the nozzles of the burners on the cooktop. . 6
Adjustment of the taps . . . . . . . . . . . . . . . . . . . . . . . . . 6
1Operating the appliance . . . . . . . . . . . . . . . . . . . 7
Burner locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cooking pans. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . 9
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com
(Important safety
information
For your safety
DO NOT MODIFY THIS APPLIANCE.
DO NOT USE OR STORE FLAMMABLE MATERIALS
NEAR THIS APPLIANCE.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHILE IT IS IN OPERATION.
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or death.
Do not store articles on or against this appliance.
What to do if you smell gas
Do not try to light the appliance.
Do not touch any electrical switch; do not use any
phone in your building.
Inmediately call your gas supplier from a neighbour’s
phone. Follow the gas supplier’s instructions.
If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by an
authorised person.
Warnings
Do not allow the flame to extend beyond the edge of
the cooking utensil. This instruction is based on safety
considerations.
Do not forget that the unit becomes hot when in use.
Common sense is important. Just because the flame is
out, does not mean parts cannot still be hot.
This appliance shall not be used for space heating. This
instruction is based on safety considerations.
Be sure to disconnect the electrical supply before
disassembly of the appliance.
Keep the appliance area clear and free from
combustible materials, gasoline and other flammable
vapours and liquids.
This appliance must be installed in a position with the
proper level of ventilation. Do not obstruct the flow of
combustion and ventilation air.
Cabinets installed above the gas cooktop must have a
minimum clearance of 650 mm (24”).
The gas pressure regulator supplied with the appliance
must be installed in line with the gas pipe. (N.G. only).
For pressure testing in excess of 3.5 kPa (1/2 psig) the
appliance and its individual shutoff valve must be
disconnected from the gas supply piping system.
Important. When using a very large pot, leave a gap of
at least 50 mm (2”) to avoid damaging any parts in
en
3
bench top wood, plastic or other non-heat resistant
materials. Never leave oil or hot fat unattended.
The surfaces on heating and cooking appliances get
hot when in use. Be careful. Keep children away from
the appliance.
Only use your appliance for the preparation of food and
never for room-heating purposes.
This appliance leaves the factory set for the gas supply
indicated on the data label. Call the Service Centre if it
needs to be altered.
Do not tamper inside the appliance. If necessary, call
your local Service Centre.
Overheated fat or oil can easily catch fire. Never leave
the appliance unattended when cooking food with fat or
oil, e.g. chips.
Never pour water on burning fat or oil. DANGER OF
BURNS! Cover the receptacle to smother the flames
and turn the cooktop off.
If the liquefied gas bottle is not upright, liquefied
propane/butane can enter the appliance. Intense
darting flames may therefore escape from the burners.
Components may become damaged and start to leak
over time so that gas escapes uncontrollably. Both can
cause burns. Always use liquefied gas bottles in an
upright position.
In the event of a fault, cut the gas and electricity
supplies to the appliance. Call our Service Centre to
repair the fault.
Do not use unstable or uneven-based receptacles on
cooking plates or burners. They may accidentally tip
over.
If a gas supply knob/valve jams, do not force it. Call
your official Service Centre immediately for them to
repair or replace it.
The illustrations used in this booklet are only intended
as a guide.
Grids become very hot during use. When operating the
appliance control knobs, take care not to make contact
with the grids.
This appliance is not suitable for use in a marine craft,
caravan or mobile home.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
Make sure you keep these instructions for use and
assembly in a safe place, so that you can hand them on
with the appliance if it ever changes owner.
Note: To avoid jeopardising the electrical safety of the
appliance, it is forbidden to use high-pressure or steam
jet cleaning devices.
SHOULD THE RELEVANT CONDITIONS NOT BE
PROPERLY SATISFIED, THE INSTALLER, AND NOT THE
MANUFACTURER, SHALL BE HELD LIABLE.
5Installation and connection
Statutory requirements
This installation must conform with the following:
■Manufacturer’s Installation instructions
■Local Gas Fitting Regulations
■Municipal Building Codes
■Refer to AS/NZS 5601.1 for Gas Installations
■S.A.A. Wiring Code
■Local Electrical Regulations
■Any other statutory regulations
Preparing to install
Refer to AS/NZS 5601.1 for piping size details. These
built-in cooktops are intended to be inserted in a
benchtop cutout.
Only an officially authorised technician should connect
the appliance.
Before you begin, turn off the gas and electricity supply.
PLQ
PLQ
PLQ
PLQ
¸
