Seite 1/3

Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST).

Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and speciﬁcations, at any time, without

notice. Consult the product’s installation instructions for ﬁnal dimensional data and other details prior to making cutout.

Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty.

For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904

24" Scoop Handle Dishwasher

300 Series – Stainless Steel SHS3ADF5N

SHS3ADF5N

Stainless Steel

The 3rd rack provides

the perfect space for

silverware and large

utensils while its V shape

leaves room below for

taller items.

Features & Beneﬁts

So quiet at 50 dBA,

InfoLight

shines on the

ﬂoor so you know the

dishwasher is running.

With PrecisionWash

intelligent sensors and

precision spray arms

target every item of every

load, so dishes come out

sparkling clean every time.

Enhance your cleaning

experience with Wi-Fi

enabled Home Connect

Access additional wash

cycles and options or

choose the right one for

your needs using Smart

Cycle.

24/7 Overﬂow Protection

System

helps prevent

water leaks, even when

your dishwasher is off.

Capacity

Number of place settings 12

Technical Details

Watts 1440 W

Current 12 Amps

Volts 120 V

Frequency 60 Hz

Power cord full length 67"

Power cord install length

from edge of unit when

facing the door

Left – 45"

Right – 56"

Minimum water pressure 14 lb/sin

Length outlet hose 90 1/2"

Dimensions & Weight

Overall appliance

dimensions (HxWxD)

33 7/8" x 23 9/16"

x 22 9/16"

Required cutout size

(HxWxD)

33 7/8" x 24" x 24"

Adjustable feet Yes

Net weight 63 lbs

Accessories—Optional

Junction Box SMZPCJB1UC

Junction Box + Supply

Hose Kit

SMZ3IN1UC

Bosch Dishwasher Water

Supply Hose

SMZSH1ABUC

Drain Hose Extension Kit SGZ1010UC

Edge Protector + Power

Cord Clip Install Kit

SMZEPCC1UC

General Properties

Wash cycles

(control panel)

5 (Heavy, Auto,

Normal, Speed60

(1hr Wash),

Favorite)

Additional wash cycles

(in Home Connect

)

3 (Delicate, Rinse,

MachineCare)

Options

(control panel)

3 (Sanitize, Remote

Start, Extra Dry)

Additional options

(in Home Connect

)

2 (Half Load, Fast

Forward)

dBA 50

Wash system PrecisionWash

Drying system PureDry

Third rack Standard 3rd Rack

Rack adjustability Manual

Tub material Stainless steel with

Polinox base

Concealed water

heating element

Yes

Leak protection system 24/7 Overﬂow

Protection

Home Connect

(WiFi enabled)

Yes

NSF

-certiﬁed* sanitize

option

Yes

Water softener No

Five-level wash Yes

Child Lock button

suspension

Anti-Fingerprint Finish Yes

Special features InfoLight on Floor,

Extra Dry Option

Efﬁciency

Water usage per cycle 3.5 gal

ENERGY STAR

Certiﬁed No

Total annual energy

consumption

269 kWh

8/25

*Certiﬁcation to NSF/ANSI Standard 184 for residential dishwashers.

Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST).

Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and speciﬁcations, at any time, without

notice. Consult the product’s installation instructions for ﬁnal dimensional data and other details prior to making cutout.

Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty.

For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904

24" Scoop Handle Dishwasher

300 Series – Stainless Steel SHS3ADF5N

Installation Details

Ø 2

/ "2

(63.5 mm)

(178 mm)

Example of Hardwire Installation

Note: Cutout

required on left or right

cabinet wall, depending on

location of water inlet, drain

and electrical connection

/ "2

(63.5 mm)

Junction box accessory

available for purchase

SMZPCJB1UC

(not included)

Ø 2

/ "2

(63.5 mm)

(178 mm)

Example of an Electrical Receptacle Installation

Note: Cutout

required on left or right

cabinet wall, depending on

location of water inlet, drain

and electrical connection

/ "2

(63.5 mm)

3-prong

power cord

included

Pre-connected

drain hose

Toe-kick

Power cord

(3-prong plug)

Included:

8/25
