Seite 1/4

CAPACITY per slot width! 1.00”! 1.25”! 1.50”

TCOREX24 2 shelves!!24! 20! devices

TCOREX36 3 shelves!!36! 30! devices

TCOREX45 3 shelves! 45! 36! 30! devices

COMPATIBILITY Designed for various sized laptops & chromebooks, yet versatile enough to

support most tablets. Uses the device manufacturer supplied AC power cord and adapter.

! OUTSIDE DIMENSIONS 29.50”W x 26.00”D x 44.75”H"

! SLOT DIMENSIONS! 1.25” or 1.50” W x 17”D x"

!!12.00”H for TCOREX24"

!!10.00”H for TCOREX36"

!!1.00” or 1.25” or 1.50”W x 17”D x"

!!10.00”H for TCOREX45"

!WEIGHT WITHOUT DEVICES! TCOREX24! 163 pounds"

!!TCOREX24B! 170 pounds"

!!TCOREX36! 175 pounds"

!!TCOREX36B! 182 pounds"

!!TCOREX45! 185 pounds"

!!TCOREX45B! 192 pounds"

! POWER MANAGER! Digital"

! POWER REQUIREMENTS ! 100 -125V ac, 12A, 50/60Hz;

! SHIPPING Ships fully assembled, ready to load devices

! WARRANTY For product speciﬁc warranty information,

! ! please visit: bretford.com/warranty

USER GUIDE

CoreX Carts

TCOREX24! CoreX Charging Cart AC for up to 24 devices w/Back Panel

TCOREX24B! CoreX Charging Cart AC for up to 24 devices w/Rear Door

TCOREX36! CoreX Charging Cart AC for up to 36 devices w/Back Panel

TCOREX36B! CoreX Charging Cart AC for up to 36 devices w/Rear Door

TCOREX45! CoreX Charging Cart AC for up to 45 devices w/Back Panel

TCOREX45B! CoreX Charging Cart AC for up to 45 devices w/Rear Door

Part # 031-10608 rev December 2016

MADE IN USA

with globally

sourced products

www.bretford.com

Technical Speciﬁcations

POWER SWITCH

Located on the

left side of the

cabinet, in the

Power Cord

Shroud

POWER CORD SHROUD

Located on the left side

of the cabinet, provides

a cord winder for the

power cord, and an IEC

outlet for plugging in the

12-foot power cord

DIRECTIONAL LOCK CASTERS

When engaged, keep the

cart rolling in the right

direction. When

unengaged, allow the cart

to be easily maneuvered

into small spaces. Marked

with a Green Locking Tab

CORD PASS-THRU ON TOP

Allows devices to be

powered outside of the

cart, while their power

cords are plugged

inside the cart.

Front View

Rear View

REAR SECURITY PANEL

VERSION

Can be securely held

in place with Security

Bolts. Panel easily lifts

off to expose the back

of the cart, where the

adapters and cord

sets are kept in cable

bins.

DOOR LOCK SHROUD

Protects the padlock

and the locking

handle during

transport

WARNING:

This cart is not intended

to hold items on the top

surface. Do not place

any item weighing more

than 1 pound on the top

surface of the cart to

avoid damage.

INTEGRATED HANDLE

Handle integrated into

the top of the cart for

pushing and moving

the cart.

USER GUIDE | CoreX CARTS

SETTING THE COMBINATION LOCK

Your new COREX Cart comes equipped with a resettable Combination Padlock. You can program the

lock with your own combination. The lock starts with 0-0-0-0. Follow the directions with the look for

changing the combination. Remember to depress the shackle before un-engaging it from the lock.

AUXILIARY OUTLET CORD

This plugs into its own IEC outlet,

and provides the power for the

cord pass-thru.

NOTICE: This auxiliary outlet

provides a maximum 2 amps.

General Use

REAR LOCKING DOOR

VERSION

Hinged rear door

provides easy access

to the back of the cart.

Door locks in place

with a key. Keys found

in the Hardware Pack.

Rear Access

Versions

Produktspezifikationen

Marke:	Bretford
Kategorie:	Handyladegerät
Modell:	TCOREX24
Breite:	838.2 mm
Tiefe:	660.4 mm
Gewicht:	73900 g
Produktfarbe:	Schwarz
Höhe:	1117.6 mm
Platzierung:	Flur
Sperren:	Ja
Zertifizierung:	UL 60950-1
Typ:	Wagen zur Verwaltung tragbarer Geräte
Gehäusematerial:	Stahl
Einstellbare Regale:	Ja
Griff(e):	Ja
Anzahl der Regale:	2 Regale
Maximale Bildschirmgröße:	- "
Anzahl der unterstützten Geräte:	24
Slot-Breite:	38.1 mm
Slot-Höhe:	304.8 mm
Slot-Tiefe:	431.8 mm
Unterstützte tragbare Geräte:	Notebook, Tablet
